两种钻头高速钻削碳纤维复合材料时的钻削力与钻削温度对比

基金项目:

国家科技重大专项资助项目(2012ZX04003031)

详细信息

Comparison of Cutting Forces and Cutting Temperatures of Two Drills in High Speed Drilling Carbon Fiber Composite

摘要: 采用金刚石涂层钻头和硬质合金麻花钻头对单向T800碳纤维复合材料进行高速钻削试验，对比分析了两种钻头在不同转速和进给速度下钻削时的钻削力与钻削温度，并研究了钻削力对制孔质量的影响。结果表明：高转速、低进给速度能有效提高孔的加工质量;在相同加工参数下，与硬质合金麻花钻头相比，用金刚石涂层钻头钻削时，钻削轴向力减小40%，钻削温度至少降低17%，更适合钻削碳纤维复合材料。
- 碳纤维复合材料 /
- 硬质合金钻头 /
- 金刚石涂层钻头 /
- 高速钻削 /
- 钻削力
Abstract: T800 carbon fiber reinforced plastic (CFRP) was drilled by diamond coated drill and carbide twist drill at high speed. The drilling axial forces and drilling temperatures produced by the two cutting tools at various rotational speeds and feet rates were studied and compared; and the effects of drilling axial force on the quality of holes were also analyzed. The results show that high rotation speed and low feed rate can improve the processing quality of holes effectively. Compared with carbide twist drill, the diamond coated drill was more suitable for drilling CFRP as its drilling axial force was reduced by 40% and drilling temperatures was at least reduced by 17% under the same processing parameters.
- CFRP /
- carbide drill /
- diamond coated drill /
- high speed drilling /
- drilling force

[1]	董博. 复合材料及碳纤维复合材料应用现状［J］. 辽宁化工, 2013(5):552-554.
[2]	WON M S, DHARAN C K H. Chisel edge and pilot hole effects in drilling composite laminates［J］. Journal of Manufacturing Science and Engineering: Transactions of the ASME, 2002, 124(2): 242-247.
[3]	汪裕炳, 张全纯. 复合材料的结构连接［M］. 北京:国防工业出版社, 1992:122-132.
[4]	鲍永杰, 高航, 李凤全. 电镀金刚石钻头钻削碳纤维复合材料研究［J］. 金刚石与磨料磨具工程, 2009(3):38-42.
[5]	张厚江, 陈五一, 陈鼎昌. 碳纤维复合材料钻削孔分层缺陷的研究［J］. 中国机械工程, 2003, 14(22):1978-1980.
[6]	FARAZ A D, BIERMANN D, WEINERT K. Cutting edge rounding: an innovative tool wear criterion in drilling CFRP composite laminates［J］. International Journal of Machine Tool &Manufacture, 2009, 49(15):1185-1196.
[7]	李桂玉, 李剑峰, 孙杰, 等. 硬质合金钻头钻削碳纤维增强复合材料工艺［J］. 粉末冶金材料科学与工程, 2010, 15(6):580-585.
[8]	王巍, 陈燕, 王伟峰, 等. 普通麻花钻与三刃麻花钻钻削碳纤维增强树脂基复合材料的性能［J］. 机械工程材料, 2012, 36(9):26-29.
[9]	胡宝刚, 赵建设, 李德茂. 碳纤维复合材料的后加工工艺［J］. 宇航材料工艺, 1995(1):31-35.
[10]	张厚江. 碳纤维复合材料(CFRP)钻削加工技术的研究［D］. 北京:北京航空航天大学, 1998:14-21.
