Effects of Al Addition on Microstructure and Electrochemical Property of FeCoCrNiMn High-Entropy Alloy in Different Treatment States
-
摘要: 采用真空熔炼技术制备了FeCoCrNiMn和Al0.3FeCoCrNiMn高熵合金，并依次进行了1 150℃×6 h均匀化处理（固溶态），室温大变形轧制及800℃×1 h退火处理（轧制退火态），研究了其固溶态和轧制退火态的显微组织及在室温0.5 mol·L-1 H2SO4溶液中的电化学性能。结果表明：固溶态2种高熵合金均由面心立方单相组成；经大变形轧制及退火处理后，FeCoCrNiMn高熵合金仍为面心立方单相组织，其晶粒尺寸细化到4.57 μm，铝的添加使合金中生成了大量富铬σ相及贫铬体心立方相，且晶粒尺寸细化到小于500 nm；不同处理态下2种高熵合金在H2SO4溶液中均出现了钝化区，铝的添加降低了FeCoCrNiMn合金的耐腐蚀性能。
-
关键词:
- FeCoCrNiMn高熵合金 /
- 铝 /
- 晶粒细化 /
- 显微组织 /
- 电化学性能
Abstract: FeCoCrNiMn and Al0.3FeCoCrNiMn high-entropy alloys were prepared by vacuum melting technique, and then subjected to homogenization treatment at 1 150℃ for 6 h (solid solution state) and severe rolling at room temperature followed by annealing at 800℃ for 1 h (rolled and annealed state). The microstructure and the electrochemical property in 0.5 mol·L-1 H2SO4 solution at room temperature of the alloys in solid solution state and in rolled and annealed state were studied. The results show that the two high-entropy alloys in solid solution state were both composed of single face-centered cubic phase. After severe rolling and annealing treatment, FeCoCrNiMn high-entropy alloy was still composed of single face-centered cubic phase, and the grains were refined to 4.57 μm; with the addition of Al, a large amount of σ phase (Cr-rich) and body-centerd cubic phase (Cr-depleted) precipitated in the alloy, and the grains were refined to lower than 500 nm. In the H2SO4 solution, the two high-entropy alloys in different treatment states possessed a passive region, and the addition of Al decreased corrosion resistance of the FeCoCrNiMn alloy. -
-
[1] YEH J W, CHEN S K, LIN S J, et al. Nanosturctured high-entropy alloys with mutiple principal elements:Novel alloy design concept and outcomes[J]. Advanced Engineering Materials, 2004, 6(5):299-303.
[2] ZHANG Y, ZHOU Y J, LIN J P, et al. Solid-solution phase formation rules for multi-component alloys[J]. Advanced Engineering Materials, 2008, 10(6):534-538.
[3] ZHANG Y, ZUO T T, TANG Z, et al. Microstructures and properties of high-entropy alloys[J]. Progress in Materials Science, 2014, 61:1-93.
[4] SANTODONATO L J, ZHANG Y, FEYGENSON M, et al. Deviation from high-entropy configurations in the atomic distributions of a multi-principal-element alloy[J]. Nature Communications, 2015, 6:5964.
[5] ZHANG Y, YANG X, LIAW P K. Alloy design and properties optimization of high-entropy alloys[J]. JOM, 2012, 64(7):830-838.
[6] SENKOV O N, WILKS G B, MIRACLE D B, et al. Refractory high-entropy alloys[J]. Intermetallics, 2010, 18(9):1758-1765.
[7] HE J Y, LIU W H, WANG H, et al. Effects of Al addition on structural evolution and tensile properties of the FeCoNiCrMn high-entropy alloy system[J]. Acta Materialia, 2014, 62:105-113.
[8] WU Y D, CAI Y H, WANG T, et al. A refractory Hf25Nb25Ti25Zr25 high-entropy alloy with excellent structural stability and tensile properties[J]. Materials Letters, 2014, 130:277-280.
[9] SCHUH B, MENDEZ-MARTIN F, VÖLKER B, et al. Mechanical properties, microstructure and thermal stability of a nanocrystalline CoCrFeMnNi high-entropy alloy after severe plastic deformation[J]. Acta Materialia, 2015, 96:258-268.
[10] LU Y, GAO X, JIANG L, et al. Directly cast bulk eutectic and near-eutectic high entropy alloys with balanced strength and ductility in a wide temperature range[J]. Acta Materialia, 2017, 124:143-150.
[11] CHUANG M H, TSAI M H, WANG W R, et al. Microstructure and wear behavior of AlxCo1.5CrFeNi1.5Tiy high-entropy alloys[J]. Acta Materialia, 2011, 59:6308-6317.
[12] LI Z, PRADEEP K G, DENG Y, et al. Metastable high-entropy dual-phase alloys overcome the strength-ductility trade-off[J]. Nature, 2016, 534(7606):227-230.
[13] TANG Z, YUAN T, TSAI C W, et al. Fatigue behavior of a wrought Al0.5CoCrCuFeNi two-phase high-entropy alloy[J]. Acta Materialia, 2015, 99:247-258.
[14] SHAHMIR H, HE J, LU Z, et al. Effect of annealing on mechanical properties of a nanocrystalline CoCrFeNiMn high-entropy alloy processed by high-pressure torsion[J]. Materials Science and Engineering:A, 2016, 676:294-303.
[15] TANG Z, GAO M C, DIAO H, et al. Aluminum alloying effects on lattice types, microstructures, and mechanical behavior of high-entropy alloys systems[J]. JOM, 2013, 65(12):1848-1858.
[16] STEPANOV N, TIKHONOVSKY M, YURCHENKO N, et al. Effect of cryo-deformation on structure and properties of CoCrFeNiMn high-entropy alloy[J]. Intermetallics, 2015, 59:8-17.
[17] OTTO F, DLOUH AY'G A, SOMSEN C, et al. The influences of temperature and microstructure on the tensile properties of a CoCrFeMnNi high-entropy alloy[J]. Acta Materialia, 2013, 61(15):5743-5755.
[18] 孙永哲, 田笑, 魏亚风, 等. 热处理对冷轧变形Al0.3CoCrFeNi高熵合金组织与力学性能的影响[J]. 材料热处理学报, 2017, 38(9):18-23. [19] LEE C P, CHEN Y Y, HSU C Y, et al. The effect of boron on the corrosion resistance of the high entropy alloys Al0.5CoCrCuFeNiBx[J]. Journal of the Electrochemical Society, 2007, 154(8):C424-C430.
[20] QIU X W, ZHANG Y P, LIU C G. Effect of Ti content on structure and properties of Al2CrFeNiCoCuTix high-entropy alloy coatings[J]. Journal of Alloys and Compounds, 2014, 585:282-286.
[21] 饶湖常, 戴品强, 陈鼎宁, 等. 碳含量对FeCoCrNiMnCx高熵合金显微组织与性能的影响[J]. 机械工程材料, 2016, 40(8):76-80. [22] CHOU Y L, YEH J W, SHIH H C. The effect of molybdenum on the corrosion behaviour of the high-entropy alloys Co1.5CrFeNi1.5Ti0.5Mox in aqueous environments[J]. Corrosion Science, 2010, 52(8):2571-2581.
[23] KAO Y F, LEE T D, CHEN S K, et al. Electrochemical passive properties of AlxCoCrFeNi (x=0, 0.25, 0.50, 1.00) alloys in sulfuric acids[J]. Corrosion Science, 2010, 52:1026-1034.
[24] 黄艺娜, 唐群华, 戴品强. 轧制变形对Al0.3CoCrFeNi高熵合金显微组织和性能的影响[J]. 机械工程材料, 2015, 39(8):41-54. [25] BAGHERPOUR E, REIHANIAN M, EBRAHIMI R. Processing twining induced plasticity steel through simple shear extrusion[J]. Materials & Design, 2012, 40:262-267.
[26] ZHENG Z J, GAO Y, GUI Y, et al. Corrosion behaviour of nanocrystalline 304 stainless steel prepared by equal channel angular pressing[J]. Corrosion Science, 2012, 54:60-67.
[27] KAO Y F, CHEN T J, CHEN S K, et al. Microstructure and mechanical property of as-cast, -homogenized, and -deformed AlxCoCrFeNi (0≤ x ≤ 2) high-entropy alloys[J]. Journal of Alloys and Compounds, 2009, 488:57-64.
[28] NILSSON J O, WILSON A. Influence of isothermal phase transformations on toughness and pitting corrosion of super duplex stainless steel SAF 2507[J]. Materials Science & Technology, 1993, 9(7):545-554.
[29] LEE C P, CHANG C C, CHEN Y Y, et al. Effect of the aluminium content of AlxCrFe1.5MnNi0.5 high-entropy alloys on the corrosion behaviour in aqueous environments[J]. Corrosion Science, 2008, 50(7):2053-2060.
