Effect of Shot Peening on Scuffing Property of Heavy-Load Gear Steel 18CrNiMo7-6
-
摘要: 分别采用传统喷丸、微粒子喷丸、传统喷丸+微粒子喷丸工艺对渗碳淬火齿轮钢18CrNiMo7-6进行表面处理，研究了喷丸处理对表面粗糙度、硬度、残余应力及胶合载荷的影响。结果表明：3种喷丸工艺均可以提高试验钢的表面硬度，传统喷丸+微粒子喷丸对表面硬度的提高幅度最大，其次为微粒子喷丸；传统喷丸增大了试验钢的表面粗糙度，微粒子喷丸和传统喷丸+微粒子喷丸降低了表面粗糙度，微粒子喷丸处理后的表面粗糙度最低；3种喷丸工艺均会在试验钢表面引入残余压应力，微粒子喷丸和传统喷丸+微粒子喷丸引入的最大残余压应力位于表面，而传统喷丸引入的位于次表面；传统喷丸+微粒子喷丸处理后试验钢的胶合载荷最大，其次为微粒子喷丸处理后的，这与微粒子喷丸提高了表面硬度和表面残余压应力，同时降低了表面粗糙度有关。Abstract: Conventional shot peening, micro-shot peening and conventional- and micro-shot peening were conducted on carburized and quenched heavy-load gear steel 18CrNiMo7-6, respectively, and then the effects of shot peening on the surface roughness, hardness, residual stress and scuffing load were studied. The results show that the surface hardness of the tested steel was improved by the three shot peening processes; the increase in surface hardness by the conventional- and micro-shot peening was the largest, followed by the micro-shot peening. The surface roughness of the tested steel was improved by conventional shot peening while reduced by micro-shot peening and by conventional- and micro-shot peening, and the surface roughness after micro-shot peening was the lowest. Residual compressive stresses were introduced to the tested steel surface by the three shot peening processes. The maximum residual compressive stresses by micro-shot peening and by conventional- and micro-shot peening were in surface, while that by conventional shot peening was in sub-surface. The scuffing load of the tested steel after conventional- and micro-shot peening was the largest, followed by micro-shot peening, due to the improvement of surface hardness and surface residual compressive stress and the decrease of surface roughness by micro-shot peening.
-
Keywords:
- shot peening /
- scuffing load /
- surface roughness /
- surface hardness /
- residual stress
-
-
[1] 薛建华, 李威. 齿轮热胶合承载能力数值计算方法研究[J]. 北京理工大学学报, 2014, 34(9):901-906. [2] DROZDOV Y N, ARCHEGOV V G. The scoring resistance of sliding metals[J]. Wear, 1981, 69(3):299-307.
[3] HORNG J H, LIN J F, LI K Y. Effet of surface-roughness on steel roller scuffing[J]. Wear, 1995, 184(2):203-212.
[4] LI Z C, FREBORG A M, HANSEN B D, et al. Modeling the effect of carburization and quenching on the development of residual stresses and bending fatigue resistance of steel gears[J]. Journal of Materials Engineering and Performance, 2013, 22(3):664-672.
[5] 戴如勇,于中奇,刘忠伟. 渗碳淬火18CrNiMo7-6钢的表面喷丸强化及表征[J]. 机械工程材料, 2013, 37(5):100-102. [6] TOWNSEND D P, ZARETSKY E V. Effect of shot peening on surface fatigue life of carburized and hardened AISI 9310 spur gears[R]. NASA Technical Report. Cleveland, Ohio:Lewis Research Center, 1982:1-12.
[7] 栾伟玲, 涂善东. 喷丸表面改性技术的研究进展[J]. 中国机械工程, 2005, 16(15):1405-1409. [8] MORITA T, NODA S, KAGAYA C. Influence of hardness of substrates on properties of surface layer formed by fine particle bombarding[J]. Materials Science and Engineering:A, 2013, 574(7):197-204.
[9] HARADA Y, FUKAURA K, HAGA S. Influence of microshot peening on surface layer characteristics of structural steel[J]. Journal of Materials Processing Technology, 2007, 191(1/2/3):297-301.
[10] IMREK H, UNUVAR A. Investigation of influence of load and velocity on scoring of addendum modified gear tooth profiles[J]. Mechanism and Machine Theory, 2009, 44(5):938-948.
[11] TERAUCHI Y, NADANO H. Effect of tooth profile modification on the scoring resistance of spur gears[J]. Wear, 1982, 80(1):27-41.
[12] THAKRE G D, SHARMA S C, HARSHA S P, et al. Tribological failure analysis of gear contacts of Exciter Sieve gear boxes[J]. Engineering Failure Analysis, 2014, 36(1):75-91.
[13] DROZDOV Y N, ARCHEGOV V G. The scoring resistance of sliding metals[J]. Wear, 1981, 69(3):299-307.
[14] WELLAUER E J, HOLLOWAY G A. Application of EHD oil film theory to industrial gear drives[J]. Journal of Engineering for Industry, 1976, 98(2):626-631.
[15] AJAYI O O, LORENZO-MARTIN C, ERCK R A, et al. Scuffing mechanism of near-surface material during lubricated severe sliding contact[J]. Wear, 2011, 271(9/10):1750-1753.
