某高频直缝电阻焊管的泄漏原因

基金项目:

国家自然科学基金资助项目（51271146）；陕西省自然科学基金资助项目（2016JQ5068）；陕西省重点学科专项资金资助项目（YS37020203）；陕西省能源化工过程强化重点实验室资助项目（SXECPI201503）

详细信息

Reason for Leakage of a High-Frequency Electric Resistance Longitudinal Welded Pipe

1. School of Materials Science and Engineering, Xi'an Shiyou University, Xi'an 710065, China;
2. CNPC Tubular Goods Research Institute, Xi'an 710077, China;
3. Petrochina West Pipeline Company, Urumqi 830013, China

摘要: 某高频直缝电阻焊管发生天然气泄漏事故。通过宏观检验、无损检测、化学成分分析、力学性能测试、金相分析、扫描电镜及能谱分析等方法，研究了该焊管的泄漏原因。结果表明：焊接工艺不当导致此焊管焊缝中存在未熔合缺陷，且在焊管制造过程中因存在漏检问题而未被发现；未熔合缺陷在服役过程中发展形成泄漏孔，最终导致泄漏。
- 高频直缝电阻焊管 /
- 泄露 /
- 未熔合
Abstract: Natural gas leakage accident occurred in a high-frequency electric resistance longitudinal welded pipe. The leakage cause of the welded pipe was analyzed by macro-examination, non-destructive testing, chemical composition analysis, mechanical property test, metallographic analysis, scanning electron microscopy and energy spectrum analysis. The results show that incomplete fusion defects were produced in the weld of the welded pipe because of the improper welding process, and were not found by missing inspection during the manufacturing of the welded pipe. Therefore the incomplete fusion defects developed and formed leak holes in service, finally leading to the leakage.
- high-frequency electric resistance longitudinal welded pipe /
- leakage /
- incomplete fusion

[1]	郭益,张璐,张维臣,等. ERW钢管在气田集输干线中的应用[J].天然气与石油,2011,29(5):21-23.
[2]	孙永喜. ERW 钢管在长输管道建设中的应用[J]. 油气储运, 2001, 20(4):47-49.[FL)]
[3]	LI L X, XIAO L, LIAO H Q, et al. Welding quality monitoring of high frequency straight seam pipe based on image feature[J]. Journal of Materials Processing Technology, 2017, 246:285-290.
[4]	唐少让, 欧耀辉, 唐宜, 等. ERW直缝焊管在生产中的质量评定[J]. 钢管, 2016, 45(3):49-51.
[5]	宋志强, 孟强, 屈德强. ERW感应焊管焊缝质量的影响因素分析[J]. 钢管, 2012, 41(4):37-41.
[6]	赵坤. 浅谈ERW钢管错边缺陷[J]. 焊管, 2008, 31(2):67-68.
[7]	刘爱民,刘法涛.影响高频直缝焊管工艺要素的分析[J].焊管,2015,38(11):29-32.
[8]	史耀武,康志新,程建秀.接合面氧化物夹杂对高频电阻焊管韧性的影响[J].焊接学报,1993,14(4):207-214.
[9]	冯耀荣,李鹤林.ERW钢管焊缝未熔合缺陷及其对性能的影响[J].焊管,1994,17(2):24-28.
[10]	王涛. ERW焊缝超声波检测系统研究[D].包头:内蒙古科技大学,2007.
