Research Progress and Application Status of Piezoelectric Materials for Vibration Control
-
摘要: 结合振动主动控制和被动控制原理，综述了应用于振动控制领域的单层压电陶瓷、多层叠堆压电陶瓷、压电纤维复合材料、0-3型压电复合材料等4种压电智能材料，重点介绍了其结构特点、制备工艺，以及在机械制造、航空航天和船舶航运等领域减振应用的研究进展，指出了压电材料的未来研究方向。
-
关键词:
- 压电陶瓷 /
- 多层叠堆 /
- 压电纤维 /
- 0-3型压电复合材料 /
- 振动控制
Abstract: On the basis of active and passive vibration control principles, four piezoelectric smart materials used in vibration control field, including single layer piezoelectric ceramics, multi-stacked piezoelectric ceramics, piezoelectric fiber composite and 0-3 type piezoelectric composite, are reviewed. The research progress of the structural characteristics, preparation process of the materails and their application for vibration attenuation in the fields of machinery manufacturing, aerospace and marine shipping are highlighted. The research direction in future of the piezoelectric materials is proposed. -
-
