Ultrasonic Testing on Grain Size of 304 Stainless Steel
-
摘要: 以不同晶粒尺寸的304奥氏体不锈钢试样为研究对象，采用频率5 MHz的超声换能器对其进行水浸横波检测，通过快速傅里叶变换（FFT）分析裂纹缺陷和晶粒反射信号的能量特征，以便排除缺陷信号的干扰；通过超声检测得到无裂纹缺陷试样的相对二阶非线性系数，分析了其与平均晶粒尺寸的关系。结果表明：当在1.6~4.4 MHz频段的能量占比低于1%时，可认为奥氏体不锈钢中无裂纹缺陷存在；相对二阶非线性系数随着奥氏体不锈钢平均晶粒尺寸的增大而减小，因此可利用该参数来表征奥氏体不锈钢的晶粒尺寸。Abstract: Taking 304 austenitic stainless steel samples with different grain size as research object, water-immersed shear wave testing was carried out with a ultrasonic transducer with frequency of 5 MHz. The energy characteristics of crack defect and grain reflection signals were analyzed by fast Fourier transform (FFT) to eliminate the interference of defect signals. Relative second-order nonlinear coefficients of samples without crack defects were obtained by ultrasonic testing, and the relationship between the coefficient and the average grain size was analyzed. The results show that when the energy proportion in 1.6-4.4 MHz band was less than 1%, we considered that no crack defects existed in the austenitic stainless steel. The relative second-order nonlinear coefficient decreased with the increase of average grain size of the austenitic stainless steel, so the parameter could be used to charaterize the grain size of austenitic stainless steel.
-
Keywords:
- 304 stainless steel /
- grain size /
- ultrasonic testing /
- fast Fourier transform /
- energy distribution
-
-
[1] 王宁,王娟,李亚江.奥氏体不锈钢应变强化研究现状[J].压力容器,2018,35(4):54-58. [2] 徐肖.晶界设计与控制对304奥氏体不锈钢力学行为的影响[D].南京:南京理工大学,2013. [3] LU K, YAN F K, WANG H T, et al. Strengthening austenitic steels by using nanotwinned austenitic grains[J]. Scripta Materialia, 2012, 66(11):878-883.
[4] 张颜艳.奥氏体不锈钢组织超声无损评价研究[D].南昌:南昌航空大学,2010. [5] 张路根,吴伟,欧阳小琴. 304不锈钢晶粒散射特性的超声检测分析[J].无损检测,2010,32(2):99-102. [6] 叶子义. 超声波检测技术在无缝钢管质量检测中的运用[J].工程技术研究, 2017(4):88-89. [7] MARINO D, KIM J Y, RUIZ A, et al. Using nonlinear ultrasound to track microstructural changes due to thermal aging in modified 9%Cr ferritic martensitic steel[J]. NDT & E International, 2016, 79:46-52.
[8] 胡丽莹,肖蓬.快速傅里叶变换在频谱分析中的应用[J].福建师范大学学报(自然科学版),2011,27(4):27-30. [9] 黎敏, 周通, 王善超,等. 基于频谱能量的材料晶粒尺寸表征方法[J].材料工程,2015,43(12):69-74. [10] 陈振华, 肖峰, 陆铭慧, 等. 微小层片型缺陷的超声非线性区域检测技术[J]. 应用声学, 2019, 38(2):200-207. [11] YAN B S, WU B, ZENG X C, et al. FEM simulation and experimental study of fatigue damage measurement in magnesium using nonlinear ultrasonic[C]//2010 International Conference on Mechanic Automation and Control Engineering. Wuhan:IEEE, 2010:11462261.
[12] 王丽梅.基于谐波和波束混叠理论的非线性超声检测技术研究[D].太原:中北大学,2016.
