Notch Sensitivity of Embrittled HR3C Steel Tube after Service
-
摘要: 在取自未服役与服役5万h HR3C钢管的拉伸试样上预制不同类型（V型、U型）、不同底部曲率半径（0.10，0.13，0.25，0.85 mm）和不同长度（0.25，0.50，0.75，1.00 mm）的缺口，通过拉伸试验研究了钢管的缺口敏感性。结果表明：未服役HR3C钢管无缺口敏感性，服役后钢管发生脆化，对缺口较为敏感；脆化态钢管对V型缺口的敏感性大于对U型缺口的，特别是对角度较大、底部曲率半径较小（0.10～0.25 mm）、长度较长（0.50～1.00 mm）的V型缺口较为敏感；当缺口应力集中系数大于3.5时，脆化态HR3C钢管的缺口敏感性较大。Abstract: Notches with different types (V, U), different root curvature radii (0.10, 0.13, 0.25, 0.85 mm) and different length (0.25, 0.50, 0.75, 1.00 mm) were pre-made in tensile samples from HR3C steel tube before and after service for 50 000 h, and then the notch sensitivity of the steel tube was studied by tensile tests. The results show that the unserviced HR3C steel tube had no notch sensitivity. After service, the steel tube was embrittled, and therefore became sensitive to notches. The embrittled steel tube had higher sensitivity to the V-notch than to the U-notch, especially being sensitive to the V-notches with a relatively large angle, relatively small root curvature radii (0.10-0.25 mm) and relatively long length (0.50-1.00 mm). When the stress concentration factor was greater than 3.5, the notch sensitivity of embrittled HR3C steel tube was high.
-
Keywords:
- HR3C steel tube /
- embrittlement /
- tensile property /
- notch sensitivity /
- stress concentration factor
-
-
[1] 牟春华, 杨征, 赵新宝, 等. 超超临界锅炉用HR3C耐热钢的研究进展[J]. 热加工工艺, 2018, 47(2):23-27. [2] ZIELI AN'G SKI A,SROKA M,HERNAS A,et al.The effect of long-term impact of elevated temperature on changes in microstructure and mechanical properties of HR3C steel[J].Archives of Metallurgy and Materials, 2016, 61(2):761-766.
[3] 于鸿垚,董建新,谢锡善.新型奥氏体耐热钢HR3C的研究进展[J].世界钢铁,2010,10(2):42-49. [4] 李明, 强文江, 郑强,等. 奥氏体钢氧化层影响因素及检测技术[C]//电力系统第十届无损检测学术会议论文集. 长沙:中国电机工程学会, 2005. [5] 王慧. HR3C钢中σ相析出动力学研究[D]. 大连:大连理工大学, 2016. [6] 赵军, 刘亚芬, 朱立新, 等. HR3C超级不锈钢焊接工艺试验研究及应用[C]//2011年安徽省科协年会——机械工程分年会论文集. 合肥:安徽省机械工程学会, 2011. [7] 吴刚. 超超临界火电用新型奥氏体耐热钢高温氧化性能研究[D]. 镇江:江苏大学, 2016. [8] 杜宝帅, 魏玉忠, 张忠文, 等. 高温服役4.2万小时超超临界机组用HR3C钢组织与性能[J]. 材料热处理学报, 2014, 35(12):84-89. [9] 罗坤杰, 赵彦芬, 张路,等. 超超临界锅炉用奥氏体耐热钢HR3C的脆化机理[J]. 材料热处理学报,2017,38(7):79-86. [10] 郑子杰.HR3C钢管时效冲击韧性大幅降低的原因分析[J].锅炉技术,2011,42(4):46-48. [11] 陈国宏,潘家栋,王家庆,等. 650℃时效HR3C耐热钢的显微组织与高温拉伸性能[J].材料热处理学报,2014,35(2):104-109. [12] ISEDA A,OKADA H,SEMBA H,et al. Long term creep properties and microstructure of SUPER304H, TP347HFG and HR3C for A-USC boilers[J]. Energy Materials, 2007, 2(4):199-206.
[13] 刘世刚,黄桥生,陈琨.1000 MW超超临界机组高温再热器管弯头失效分析[J].电力科技与环保,2017,33(2):60-62. [14] 刘海军, 曹睿, 何洪,等. K418合金缺口敏感性研究[J]. 稀有金属, 2010, 34(5):699-704. [15] 静永娟,高帆,付明杰,等.单一取向层片组织TiAl合金缺口敏感性的研究[J].物理测试,2010,28(2):24-27. [16] 李昂,张毅,高蔚,等.缺口效应对7178铝合金拉伸性能及断口形貌的影响[C]//中国核学会2017年学术年会论文集第5册(核材料分卷、辐射防护分卷).威海:中国核协会,2017.
