Effect of Process Parameters on Morphology and Property of Vacuum Diffusion Welded Joint of 6061-T6 Aluminum Alloy
-
摘要: 在不同工艺参数下对化学清洗去除表面氧化膜的6061-T6铝合金进行真空扩散焊接，研究了焊接温度（500~560℃）、焊接压力（1.0~5.0 MPa）和保温时间（0.5~3 h）对焊接接头界面形貌和剪切强度的影响，得到了优化工艺参数。结果表明：随着焊接温度的升高、焊接压力的增大和保温时间的延长，接头焊缝变窄并最终消失，剪切强度和焊合率增大；但当保温时间延长到3 h时，焊缝附近晶粒发生粗化，导致剪切强度降低，且接头发生较大变形；不同工艺参数下接头的剪切断裂形式均为脆性断裂；较优的真空扩散焊接工艺参数为焊接温度540℃、保温时间2 h、焊接压力4.0 MPa。Abstract: Vacuum diffusion bonding with different process parameters was conducted on 6061-T6 aluminum alloy after removing surface oxide films by chemical cleaning. Effects of bonding temperatures (500-560℃), bonding pressures (1.0-5.0 MPa) and holding times (0.5-3 h) on the interface morphology and shear strength of the welded joint were studied, and the optimal process parameters were determined. The results show that with the increase of the bonding temperature, bonding pressure and holding time, the weld seam of the joint became narrow and finally disappeared; the shear strength and welding rate were improved. However, when the holding time was extended to 3 h, the grains near the weld seam became coarse, leading to the decrease in the shear strength, and the joint had large deformation. The shear fracture modes of the joints with different process parameters were all brittle fracture. The optimal process parameters for the vacuum diffusion bonding were listed as follows:bonding temperature of 540℃, holding time of 2 h, and bonding pressure of 4.0 MPa.
-
-
[1] 郭夏阳, 林建平, 孙博. 扩散焊技术的研究进展[J]. 热加工工艺, 2014, 43(17):15-20. [2] 何辰佳, 陈明和, 谢兰生. TC4钛合金扩散连接工艺研究[J]. 热加工工艺, 2017, 46(17):64-68. [3] 熊金平, 赵艺阁, 周勇,等. 铝合金表面氧化膜去除方法研究进展[J]. 电镀与精饰, 2013, 35(11):15-19. [4] 熊江涛, 张赋升, 李京龙. 减小表面氧化膜对LD2扩散焊接头不利影响的工艺[J]. 焊接, 2004(6):22-24. [5] 赵明久, 吕毓雄, 陈礼清, 等. 碳化硅颗粒增强铝基复合材料(SiCp/2024Al)的扩散焊研究[J]. 材料研究学报, 2000, 14(2):136-140. [6] 刘浩, 柯孚久, 潘晖, 等. 铜-铝扩散焊及拉伸的分子动力学模拟[J].物理学报, 2007, 56(1):407-412. [7] ZHANG J, LUO G Q, WANG Y Y, et al. An investigation on diffusion bonding of aluminum and magnesium using a Ni interlayer[J]. Materials Letters, 2012, 83:189-191.
[8] 胡学术. TC4/1060Al低温扩散焊接及其接头性能研究[D]. 武汉: 武汉理工大学, 2015. [9] 李维伟. 5083铝合金扩散焊接工艺研究[D]. 南京: 南京航空航天大学, 2007. [10] CHEN M S, FAN F Y, LIN C K, et al. Enhanced diffusion bonding between high purity aluminum and 6061 aluminum by electrolytic polishing assistance[J]. International Journal of Electrochemical Science, 2016, 11: 4922-4929.
[11] COOPER D R, ALLWOOD J M. Influence of diffusion mechanisms in aluminium solid-state welding processes[J]. Procedia Engineering, 2014, 81: 2147-2152.
[12] 潘复生, 张丁非. 铝合金及应用[M]. 北京: 化学工业出版社, 2007.
