Preparation and Microstructure of C/Al-40%Cu Composite by In-situ Pyrolysis and Hot-Pressing Method
-
摘要: 以聚乙烯醇缩丁醛为碳源，采用原位热解-热压法制备C/Al-40% Cu （体积分数）复合材料，研究了该复合材料的物相组成、微观结构以及界面反应特性。结果表明：复合材料主要由铝相、铜相、原位生成的碳材料以及少量残留的高分子材料组成，碳材料连续存在于铝、铜相颗粒之间，有效抑制了Al2Cu和Al4Cu9等金属间化合物的生成；复合材料的实测密度接近于理论密度，组织中未见明显孔洞，致密程度较高；复合材料界面结合良好，铝相和铜相、铝相和碳材料层之间均发生了元素互扩散，形成了厚度分别为2.0~3.5 μm和1.0~1.5 μm的扩散层，铜相和碳材料层之间以机械结合方式连接。
-
关键词:
- C/Al-Cu复合材料 /
- 原位热解-热压 /
- 界面扩散
Abstract: With polyvinyl butyral as carbon source,C/Al-40%Cu (volume fraction) composite was prepared by in-situ pyrolysis and hot-pressing method. The phase composition, microstructure and interface reaction characteristics of the composite were studied. The results show that the composite was mainly composed of aluminum phase, copper phase, in-situ produced carbon materials and few residual polymers. The carbon materials continuously existed between aluminum and copper grains, effectively inhibiting the generation of Al2Cu and Al4Cu9 intermetallic compounds. The measured density of the composite was close to the theoretical density, and no obvious pores were observed in the structure, indicating a relatively high densification degree. The interfaces of the composite were well bonded. The elemental interdiffusion occured between the aluminum phase and the copper phase, and between the aluminum phase and the carbon material layer, forming diffusion layers with thicknesses of 2.0-3.5 μm and 1.0-1.5 μm, respectively. The copper phase and the carbon material layer were bonded mechanically. -
-
[1] CHENG X L, GAO Y M, FU H G, et al. Microstructural characterization and properties of Al/Cu/steel diffusion bonded joints[J]. Metals and Materials International, 2010, 16(4):649-655.
[2] KIM I K, HONG S I. Effect of heat treatment on the bending behavior of tri-layered Cu/Al/Cu composite plates[J]. Materials & Design, 2013, 47:590-598.
[3] SAEID T, ABDOLLAH-ZADEH A, SAZGARI B. Weldability and mechanical properties of dissimilar aluminum-copper lap joints made by friction stir welding[J]. Journal of Alloys and Compounds, 2010, 490(1/2):652-655.
[4] XIA C Z, LI Y J, WANG J, et al. Microstructure and phase constitution near interface of Cu/Al vacuum brazing[J]. Materials Science and Technology, 2007, 23(7):815-818.
[5] HUANG G Q, HOU W T, LI J P, et al. Development of surface composite based on Al-Cu system by friction stir processing:Evaluation of microstructure, formation mechanism and wear behavior[J]. Surface and Coatings Technology, 2018, 344:30-42.
[6] RAJESHKUMAR R, UDHAYABANU V, SRINIVASAN A, et al. Microstructural evolution in ultrafine grained Al-Graphite composite synthesized via combined use of ultrasonic treatment and friction stir processing[J]. Journal of Alloys and Compounds, 2017, 726:358-366.
[7] SINGLA D, AMULYA K, MURTAZA Q. CNT reinforced aluminium matrix composite:A review[J]. Materials today:Proceedings, 2015, 2(4/5):2886-2895.
[8] MOLINA-JORDÁ J M. Design of composites for thermal management:Aluminum reinforced with diamond-containing bimodal particle mixtures[J]. Composites Part A, 2015, 70:45-51.
[9] JIANG L, LI Z Q, FAN G L, et al. Strong and ductile carbon nanotube/aluminum bulk nanolaminated composites with two-dimensional alignment of carbon nanotubes[J]. Scripta Materialia, 2012, 66(6):331-334.
[10] BARTOLUCCI S F,PARAS J,RAFIEE M A,et al.Graphene-aluminum nanocomposites[J].Materials Science and Engineering:A, 2011,528(27):7933-7937.
[11] NAJI H, ZEBARJAD S M, SAJJADI S A. The effects of volume percent and aspect ratio of carbon fiber on fracture toughness of reinforced aluminum matrix composites[J]. Materials Science and Engineering:A,2008,486(1/2):413-420.
[12] CHEN J K, HUANG I S. Thermal properties of aluminum-graphite composites by powder metallurgy[J]. Composites Part B, 2013, 44(1):698-703.
[13] TAN Z Q, JI G, ADDAD A, et al. Tailoring interfacial bonding states of highly thermal performance diamond/Al composites:Spark plasma sintering vs. vacuum hot pressing[J]. Composites Part A, 2016, 91:9-19.
[14] LIU Z G, MANG X B, CHAI L H, et al. Interface study of carbon fibre reinforced Al-Cu composites[J]. Journal of Alloys and Compounds, 2010, 504(S1):512-514.
[15] GUO B S, CHEN B, ZHANG X M, et al. Exploring the size effects of Al4C3 on the mechanical properties and thermal behaviors of Al-based composites reinforced by SiC and carbon nanotubes[J]. Carbon, 2018, 135:224-235.
[16] LIU Z Y, XU S J, XIAO B L, et al. Effect of ball-milling time on mechanical properties of carbon nanotubes reinforced aluminum matrix composites[J]. Composites Part A, 2012, 43(12):2161-2168.
[17] ZHOU W W, BANG S, KURITA H, et al. Interface and interfacial reactions in multi-walled carbon nanotube-reinforced aluminum matrix composites[J]. Carbon, 2016, 96:919-928.
[18] SHEN Q, ZHOU D Q, ZHANG J, et al. Study on preparation and property of porous tungsten via tape-casting[J]. International Journal of Refractory Metals and Hard Materials, 2017, 69:27-30.
