Effect of Post-Weld Coating Process on Microstructure and Properties of 6063-T6 Aluminum Alloy MIG Welded T-Joint
-
摘要: 采用金属熔化极惰性气体保护（MIG）焊制备6063-T6铝合金T型接头，之后对T型接头进行涂装，研究了焊后涂装工艺对接头组织与性能的影响。结果表明：涂装工艺对接头各区域晶粒形态和尺寸没有影响，涂装后热影响区中针状β″相析出量明显增加；焊后涂装可以显著提高接头的力学性能，抗拉强度较涂装前的提高了13%，热影响区的显微硬度较涂装前的提高了18.8%；涂装完成前，接头最薄弱区域为热影响区，而涂装完成后，最薄弱区域为焊缝处；涂装后镁、硅原子在热影响区富集形成溶质原子富集区（GP区），同时针状β″相析出量的增加干扰位错运动，导致热影响区的硬度大幅提高，而使焊缝处成为接头的最薄弱区域。
-
关键词:
- 6063-T6铝合金 /
- 涂装工艺 /
- T型接头 /
- 显微组织 /
- 力学性能
Abstract: T-joint of 6063-T6 aluminum alloy was prepared by metal inert gas (MIG) welding and then coated. The influence of the post-weld coating process on the structure and properties of the joint was studied. The results show that the coating process had no effect on the grain morphology and size of each region of the joint. The amount of acicular β″ phase precipitation in heat affected zone increased significantly after coating. The mechanical properties of the joint were significantly improved after post-weld coating; the tensile strength was 13% higher than that before coating; the microhardness of the heat-affected zone was 18.8% higher than that before coating. The weakest area of the joint was the heat affected zone before coating, and was the weld zone after coating. Magnesium and silicon atoms were enriched in the heat affected zone to form a solute atoms-rich zone, the GP (Guinier & Preston) zone; meanwhile, the increase of acicular β″ phase precipitation disturbed the movement of dislocations, resulting in the significant increase of the hardness of the heat affected zone, and making the weld seam the weakest area of the joint.-
Keywords:
- 6063-T6 aluminum alloy /
- coating process /
- T-joint /
- microstructure /
- mechanical property
-
-
[1] MILLER W S, ZHUANG L, BOTTEMA J, et al. Recent development in aluminium alloys for the automotive industry[J]. Materials Science & Engineering:A, 2000, 280(1):37-49.
[2] FRIDLYANDER I N, SISTER V G, GRUSHKO O E, et al.Aluminum alloys:Promising materials in the automotive industry[J]. Metal Science & Heat Treatment, 2002, 44(9/10):365-370.
[3] IMAM M, RACHERLA V, BISWAS K. Effect of post-weld natural aging on mechanical and microstructural properties of friction stir welded 6063-T4 aluminium alloy[J]. Materials & Design, 2014, 64:675-686.
[4] IMAM M, RACHERLA V, BISWAS K, et al. Microstructure-property relation and evolution in friction stir welding of naturally aged 6063 aluminium alloy[J]. International Journal of Advanced Manufacturing Technology, 2016, 91(5/6/7/8):1-17.
[5] AHMAD R, BAKAR M A. Effect of a post-weld heat treatment on the mechanical and microstructure properties of AA6061 joints welded by the gas metal arc welding cold metal transfer method[J]. Materials & Design, 2011, 32(10):5120-5126.
[6] 宋东福,戚文军,梁涛,等.焊后时效对6061-T6铝合金搅拌摩擦焊接头的影响[J].稀有金属,2012,36(4):535-540. [7] 邹家生,刘欣,许祥平.6063铝合金焊接接头热处理工艺研究[J].焊接技术,2014,43(4):31-34. [8] 欧玉春, 童忠良. 汽车涂料涂装技术[M]. 北京:化学工业出版社, 2010. [9] 王飞. 汽车涂装工艺及涂料研究[D].西安:长安大学,2015. [10] 马严玮,王宝雨,校文超,等.固溶时效工艺对6016铝合金力学性能的影响及多目标优化[J].工程科学学报,2017,39(1):75-80. [11] SATO Y S, URATA M, KOKAWA H. Parameters controlling microstructure and hardness during friction-stir welding of precipitation-hardenable aluminum alloy 6063[J]. Metallurgical and Materials Transactions A, 2002, 33(3):625-635.
[12] 王希靖,魏学玲,张亮亮.焊后时效处理对6082-T6铝合金搅拌摩擦焊接头的影响[J].材料导报,2017,31(8):62-65. [13] ELANGOVAN K, BALASUBRAMANIAN V.Influences of post-weld heat treatment on tensile properties of friction stir-welded AA6061 aluminum alloy joints[J]. Materials Characterization, 2008, 59(9):1168-1177.
[14] TSAO C S, CHEN C Y, JENG U S, et al. Precipitation kinetics and transformation of metastable phases in Al-Mg-Si alloys[J]. Acta Materialia, 2006, 54(17):4621-4631.
[15] 赵志浩, 徐振, 王高松, 等. 微合金化4043铝合金焊丝焊接接头的组织与性能[J]. 金属学报, 2013, 49(8):946-952. [16] YAMADA K, SATO T, KAMIO A. Effects of quenching conditions on two-step aging behavior of Al-Mg-Si alloys[J]. Materials Science Forum, 2000, 331:669-674.
[17] DUDZIK K, CHARCHALIS A. Influence of friction stir welding on hardness distribution in joints of AlZn5Mg1 alloy[J]. Solid State Phenomena, 2013, 199:430-435.
[18] 许良红, 田志凌, 彭云,等. 微量元素对高强铝合金焊缝组织和力学性能的影响[J]. 中国有色金属学报, 2008, 18(6):959-966. [19] 彭小燕,曹晓武,段雨露,等.7020铝合金MIG焊焊接接头的组织与性能[J].中国有色金属学报,2014,24(4):912-918. [20] ARES A E, GUEIJMAN S F, CARAM R, et al. Analysis of solidification parameters during solidification of lead and aluminum base alloys[J]. Journal of Crystal Growth, 2005, 275(1):319-327.
[21] HU B, RICHARDSON I M. Microstructure and mechanical properties of AA7075(T6) hybrid laser/GMA welds[J]. Materials Science & Engineering:A, 2007, 459(1/2):94-100.
