Effect of High Current Pulsed Electron Beam Treatment on Surface Microstructure and Properties of GW103K Magnesium Alloy
-
摘要: 采用强流脉冲电子束（HCPEB）对GW103K镁合金进行表面处理，研究了不同脉冲次数（5次，15次）处理后合金的表面微观结构、硬度和耐腐蚀性能。结果表明：经HCPEB处理后，GW103K镁合金表面存在大量火山坑、收缩针孔和孪晶，原始组织中的β-Mg5（Gd，Y）颗粒基本溶解在基体中；15次脉冲HCPEB处理后合金的表面形貌和化学成分比5次脉冲HCPEB处理后的更均匀；随着HCPEB脉冲次数由5次增加到15次，合金表面重熔层的厚度由约7.67 μm增加到约13.70 μm；HCPEB处理后距表面50~250 μm处的显微硬度均高于基体的，且均在距表面约70 μm处达到最大；在质量分数3.5％NaCl溶液中，经5次脉冲HCPEB处理后合金的自腐蚀电流密度最小，耐腐蚀性能最好，这与钆、钇的溶解以及表面残余压应力有关。Abstract: The surface treatment of GW103K magnesium alloy was carried out by high current pulsed electron beam (HCPEB). The surface microstructure, hardness and corrosion resistance of the alloy after HCPEB treatment with different pulses (5, 15 pulses) were investigated. The results show that after HCPEB treatment, the surface of GW103K magnesium alloy had a large number of craters, pinholes and twins, and the β-Mg5(Gd, Y) phase observed in original structure was dissolved in the matrix. The surface morphology and chemical composition of the alloy after 15-pulse HCPEB treatment were more uniform than those after 5-pulse HCPEB treatment. As the HCPEB pulses increased from 5 to 15, the thickness of the remelted layer on the alloy surface increased from about 7.67 μm to about 13.70 μm. After HCPEB treatment, the values at a distance of 50 μm to 250 μm from the surface was higher than that of the matrix, and reached the maximum values at a distance of about 70 μm from the surface. In the 3.5wt% NaCl solution, the free-corrosion current density of the alloy after 5-pulse HCPEB treatment was the smallest and the corrosion resistance was the best, ascribing to the dissolution of thorium and yttrium and the surface residual compressive stress.
-
-
[1] AVEDESIAN M M, BAKER H.ASM speciality handbook magnesium and magnesium alloys[M]. OH:ASM International, 1999.
[2] 黄亮, 黄元伟, 王晨, 等.含稀土元素的Mg-Al合金在NaCl溶液中腐蚀产物膜的研究[J].中国腐蚀与防护学报, 2002, 22(3):167-171. [3] 杨素媛, 张丽娟, 张堡垒.稀土镁合金的研究现状及应用[J]. 稀土, 2008, 29(4):81-86. [4] 余强国, 翁国庆.稀土镁合金的发展、应用及开发[J].稀有金属与硬质合金, 2006, 34(3):36-38. [5] 王荣滨.稀土在镁合金中的作用与应用研究[J]. 有色金属加工, 2007, 36(1):27-29. [6] NEGISHI Y, NISHIMURA T, IWASAWA S, et al.Aging characteristics and tensile properties of Mg-Gd-Nd-Zr alloys[J]. Light Metals, 1994, 44(10):555-561.
[7] KOVALN N, IVANOVY F.Nanostructuring of surfaces of metalloceramic and ceramic materials by electron-beams[J]. Russian Physics Journal, 2008, 51:505-516.
[8] GROSDIDIER T, ZOU J X, STEIN N, et al.Texture modification, grain refinement and improved hardness/corrosion balance of a FeAl alloy by pulsed electron beam surface treatment in the "heating mode"[J]. Scripta Materialia, 2008, 58:1058-1061.
[9] HAO S Z, WU P S, ZOU J X, et al.Microstructure evolution occurring in the modified surface of 316L stainless steel under high current pulsed electron beam treatment[J]. Applied Surface Science, 2007, 253:5349-5351.
[10] XU Y, ZHANG Y, HAO S Z, et al.Surface microstructure and mechanical property of WC-6%Co hard alloy irradiated by high current pulsed electron beam[J].Applied Surface Science, 2013, 279:137-141.
[11] LI M C, HAO S Z, DONG C.Improved wear resistance of magnesium alloys AZ91 by high current pulsed electron beam treatment[J]. Transactions of the Indian Institute of Metals, 2009, 62:485-490.
[12] GAO B, HAO S Z, ZOU J X, et al.Study on continuous solid solution of Al and Si elements of a high current pulsed electron beam treated hypereutectic Al17.5Si alloy[J]. Surface and Coatings Technology, 2007, 201:62-97.
[13] ZOU J X, ZHANG K M, GROSDIDIER T, et al.Analysis of the evaporation and re-condensation processes induced by pulsed beam treatments[J]. International Journal of Heat & Mass Transfer, 2013, 64:1172-1182.
[14] ZOU J X, GROSDIDIER T, ZHANG K M, et al.Cross-sectional analysis of the graded microstructure in an AISI D2-steel treated with low energy high-current pulsed electron beam[J]. Applied Surface Science, 2009, 255:4758-4764.
[15] LIU Y R, ZHANG K M, ZOU J X, et al.Effect of the high current pulsed electron beam treatment on the surface microstructure and corrosion resistance of a Mg-4Sm alloy[J]. Journal of Alloys and Compounds, 2018, 65-75.
[16] ZHANG K M, YANG D Z, ZOU J X, et al.Surface modification of 316L stainless steel by high current pulsed electron beam Part I:Selective surface purification and its mechanism[J].Acta Metallurgica Sinica, 2007, 43:64-70.
[17] HAO Y, GAO B, TU G F, et al.Improved wear resistance of Al-15Si alloy with a high current pulsed electron beam treatment[J]. Nuclear Instruments and Methods in Physics Research Section B:Beam Interactions with Materials and Atoms, 2011, 269:1499-1505.
[18] ZHANG K M, ZOU J X, GROSDIDIER T, et al.Improved pitting corrosion resistance of AISI 316L stainless steel treated by HCPEB[J]. Surface and Coatings Technology, 2006, 201:1393-1400.
[19] JAHEDI M, MOY P, KNEZEVIC M, et al. Deformation twinning in rolled WE43-T5 rare earth magnesium alloy:Influence on strain hardening and texture evolution[J]. Acta Materialia, 2017, 131:221-232.
[20] GAO B, HAO Y, TU G, et al.Surface modification of Mg67-Zn30-Y3 quasicrystal alloy by high current pulsed electron beam[J]. Surface and Coatings Technology,2013,229:42-45.
[21] 吴爱民, 刘捍卫, 邹建新, 等.D2钢电子束表面改性抗微动磨损性能研究[J]. 核技术, 2002, 25(9):758-765. [22] YANG P, YU Y, CHEN L, et al.Experimental determination and theoretical prediction of twin orientations in magnesium alloy AZ31[J]. Scripta Materialia, 2004, 50:1163-1168.
[23] XU F, TANG G, GUO G, et al.Influence of irradiation number of high current pulsed electron beam on the structure and properties of M50 steel[J]. Nuclear Instruments and Methods in Physics Research Section B:Beam Interactions with Materials and Atoms, 2010, 268:2395-2399.
[24] LIU X, FRANKEL G S, Effects of compressive stress on localized corrosion in AA2024-T3[J]. Corrosion Science, 2006, 48:3309-3329.
