Microstructure and Wear Resistance of Iron-Based Laser Cladding Layer on Surface of 35CrMo Steel
-
摘要: 采用CO2激光熔覆装置将LC3530铁基粉熔覆在35CrMo钢基体表面，研究了熔覆层的显微组织、硬度和耐磨性能，并与基体的进行对比。结果表明：基体组织为回火索氏体，晶粒尺寸在20 μm左右，而熔覆层的组织为均匀细小的等轴晶，晶粒尺寸大多在8 μm；基体的平均硬度为254.1 HV，而熔覆层的平均硬度为640.5 HV，且硬度分布更加均匀；在相同试验条件下，熔覆层试样的磨损量仅为基体试样的1/7，磨损系数是基体试样的1/5，且磨损后熔覆层试样的表面粗糙度较磨损前的大幅下降，表明激光熔覆后35CrMo钢的耐磨性能得到显著提高；基体试样的磨损机制为犁削磨损，而熔覆层试样的磨损机制为微观切削，其优异的耐磨性能与含有铁、铬、钼和碳等元素的高硬度合金碳化物的形成有关。Abstract: LC3530 iron-based powder was cladded on the surface of 35CrMo steel substrate by CO2 laser cladding device. The microstructure, hardness and wear resistance of cladding layer were studied and compared with those of substrate. The results show that the microstructure of the substrate was tempered sorbite, and the grain size was about 20 μm; the microstructure of the cladding layer was uniform and fine equiaxed grains, and the grain size was mostly 8 μm. The average hardness of substrate was 254.1 HV, while that of cladding layer was 640.5 HV and the distribution of hardness was more uniform. Under the same test conditions, the wear loss and wear coefficient of the cladding layer sample were only 1/7 and 1/5 of those of the substrate, respectively; the roughness of the cladding layer sample after wear was significantly lower than that before wear, indicating that the wear resistance of 35CrMo steel was significantly improved after laser cladding. The wear mechanism of the substrate was plough wear; the wear mechanism of the cladding layer was microscopic cutting, and its excellent wear resistance was related to the formation of high hardness alloy carbides containing iron, chromium, molybdenum and carbon.
-
Keywords:
- 35CrMo steel /
- laser cladding /
- microstructure /
- wear resistance
-
-
[1] 陈晋琳,周亚军,石琛,等. 电磁搅拌熔体处理对回转轴组织和性能的影响[J]. 特种铸造及有色合金, 2017(2):179-182. [2] LIANG G, SHI C, ZHOU Y, et al. Effect of ultrasonic treatment on the solidification microstructure of die-cast 35CrMo steel[J]. Metals, 2016, 6(11):260-268.
[3] CHEN J, ZHOU Y, SHI C, et al. Microscopic analysis and electrochemical behavior of Fe-based coating produced by laser cladding[J]. Metals, 2017, 7(10):435-444.
[4] YAO J, ZHANG J, WU G, et al. Microstructure and wear resistance of laser cladded composite coatings prepared from pre-alloyed WC-NiCrMo powder with different laser spots[J]. Optics & Laser Technology, 2018, 101:520-530.
[5] FU Z K, DING H H, WANG W J, et al. Investigation on microstructure and wear characteristic of laser cladding Fe-based alloy on wheel/rail materials[J]. Wear, 2015, 330/331:592-599.
[6] HAN B, LI M, WANG Y. Microstructure and wear resistance of laser clad Fe-Cr3C2 composite coating on 35CrMo steel[J]. Journal of Materials Engineering and Performance, 2013, 22(12):3749-3754.
[7] YANG Y, ZHANG D, YAN W, et al. Microstructure and wear properties of TiCN/Ti coatings on titanium alloy by laser cladding[J]. Optics & Lasers in Engineering, 2010, 48(1):119-124.
[8] WANG C, CHEN J, XIA Z C, et al. Die wear prediction by defining three-stage coefficient K for AHSS sheet metal forming process[J]. The International Journal of Advanced Manufacturing Technology, 2013, 69(1/2/3/4):797-803.
[9] 黄元春,黄雨田,肖政兵,等. 35CrMo钢控温模锻加热过程中奥氏体晶粒长大行为[J]. 粉末冶金材料科学与工程, 2016(4):645-651. [10] 许妮君,刘常升,吕建斌,等. 10 V高速钢激光熔覆层的组织与性能[J]. 材料与冶金学报, 2018(3):222-227. [11] 任建华,杨晓良,黄浩,等. 40Cr模具钢激光熔覆层组织及性能分析[J]. 模具工业, 2017(7):59-61. [12] 吴渊. 基于FeCoNiCrMn高熵合金的晶粒生长和霍尔-佩奇关系研究取得新进展[J]. 中国表面工程, 2015, 28(3):131. [13] CHEN J, GUO C, ZHOU J. Microstructure and tribological properties of laser cladding Fe-based coating on pure Ti substrate[J]. Transactions of Nonferrous Metals Society of China, 2012, 22(9):2171-2178.
[14] WU C, MA M, LIU W, et al. Laser cladding in-situ carbide particle reinforced Fe-based composite coatings with rare earth oxide addition[J]. Journal of Rare Earths. 2009, 27(6):997-1002.
[15] 何骅波, 杨梦梦, 黄晓波, 等. 螺杆钢表面不同激光熔覆层的耐磨与耐腐蚀性能[J]. 机械工程材料, 2017, 41(10):11-14. [16] 刘瑾,祁荣欣,曲明贵,等. 高锰钢表面激光熔覆及性能研究[J]. 热加工工艺, 2010(24):189-191. [17] ZHANG X, ZHOU Y J. Effect of deep cryogenic treatment on microstructure and wear resistance of LC3530 Fe-based laser cladding coating[J]. Materials, 2019,12(15):2400.
