Analytical Solutions of Thermal Residual Stress and Deformation of 3D Printed Parts
-
摘要: 针对三维打印工件的热残余应力和变形现象，引入底板和动态降温梯度两个关键要素，建立了三维打印过程中热残余应力和变形的解析表达式，并进行了算例验证。结果表明：引入底板和动态降温梯度后，计算结果与实际情况相符；底板温度与成形温度相差越大，降温梯度、热残余应力和变形越大；打印完成后无论何时拆除底板都不会影响热残余应力和变形程度；忽略底板的影响会使解析解产生很大的误差；底板保持恒温可显著降低热残余应力，且保温温度越接近制备温度，热残余应力越小。Abstract: For the thermal residual stress and deformation phenomenon of 3D printing parts, two key factors of platform and dynamic cooling gradient were introduced, and the analytical expressions of thermal residual stress and deformation were established and verified by numerical examples. The results show that the calculation was consistent with the actual situation after introducing the platform and dynamic cooling gradient. The greater the difference between the platform temperature and the forming temperature, the greater the cooling gradient, the thermal residual stress and the deformation. The platform removal time after printing had no effect on the thermal residual stress and deformation level, but ignoring the influence of the platform caused a large error in the analytical solution. Keeping the platform at a constant temperature significantly reduced the thermal residual stress, and the closer the holding temperature to the printing temperature, the lower the thermal residual stress.
-
Keywords:
- 3D printing /
- thermal residual stress /
- deformation /
- platform /
- gradient cooling /
- analytical solution
-
-
[1] NING F D,CONG W L,QIU J J,et al.Additive manufacturing of carbon fiber reinforced thermoplastic composites using fused deposition modeling[J].Composites Part B:Engineering,2015,80:369-378.
[2] POPESCU D,ZAPCIU A,AMZA C,et al.FDM process parameters influence over the mechanical properties of polymer specimens:A review[J].Polymer Testing,2018,69:157-166.
[3] SUN B B,KULINSKY L.Fabrication of regular polystyrene foam structures with selective laser sintering[J].Materials Today Communications,2017,13:346-353.
[4] 舒小平.叠层制备结构热应力分析[M].南京:南京大学出版社,2015. [5] WANG J, DAS S, RAI R, et al. Data-driven simulation for fast prediction of pull-up process in bottom-up stereo-lithography[J]. Computer-Aided Design, 2018, 99:29-42.
[6] ZHAO X R,IYER A,PROMOPPATUM P,et al.Numerical modeling of the thermal behavior and residual stress in the direct metal laser sintering process of titanium alloy products[J].Additive Manufacturing,2017,14:126-136.
[7] ZHANG X C,XU B S,WANG H D,et al.An analytical model for predicting thermal residual stresses in multilayer coating systems[J].Thin Solid Films,2005,488(1/2):274-282.
[8] WANG L,WANG Y,SUN X G,et al.Finite element simulation of residual stress of double-ceramic-layer La2Zr2O7/8YSZ thermal barrier coatings using birth and death element technique[J].Computational Materials Science,2012,53(1):117-127.
[9] EL MOUMEN A,TARFAOUI M,LAFDI K.Additive manufacturing of polymer composites:Processing and modeling approaches[J].Composites Part B:Engineering,2019,171:166-182.
[10] ÖHMAN M,EKH M,LARSSON F,et al.Finite element simulations of thermal residual stresses in realistic 3D WC-Co microstructures[J].International Journal of Refractory Metals and Hard Materials,2019,85:105065.
[11] ALMOTAIRI A,FARHAT Z,WARKENTIN A.Thermal damage of conventional hard chromium coatings on 416 stainless steel[J].Engineering Failure Analysis,2019,105:1118-1130.
[12] 曹师增,宋发成,刘元义,等.基于FDM的3D打印翘曲变形优化研究[J].塑料工业,2017,45(10):51-54. [13] SHU X P,WANG R L.Thermal residual solutions of beams,plates and shells due to laminated object manufacturing with gradient cooling[J].Composite Structures,2017,174:366-374.
[14] 王荣亮,舒小平.基于梯度降温的叠层制备热残余解析解[J].现代制造工程,2017(11):65-69. [15] 舒小平,张少林.三维打印碳纤维增强聚合物复合材料热残余解析解[J].复合材料学报,2019,36(5):1151-1158.
