Laser Cladding Process of Flow Channel in 316L Stainless SteelBipolar Plate for Fuel Cells
-
摘要: 通过激光熔覆成形工艺制备了316L不锈钢燃料电池双极板流道，根据双极板流道结构要求，建立了熔覆道成形量化评分标准，通过正交试验研究了激光功率、扫描速度、铺粉厚度对熔覆道成形性能和耐腐蚀性能的影响。结果表明：铺粉厚度、激光功率、扫描速度对熔覆道成形影响的显著性依次减小；较低的激光功率、较高的扫描速度、较小的铺粉厚度以及较低的热输入，有利于获得成形更好的熔覆道；激光功率和扫描速度的增加均有利于提高熔覆道的耐点蚀性能；熔覆道成形效果越好，耐点蚀性能越好。Abstract: The 316L stainless steel bipolar plate for fuel cells was prepared by laser cladding forming process. According to the requirements of bipolar plate channel structure, the quantitative scoring standard of cladding channel was established. The effects of laser power, scanning speed and powder thickness on formability and corrosion resistance of the cladding channel were studied by orthogonal experiment. The results show that the effect of spreading powder thickness, laser power, and scanning speed on the formation of cladding channels decreased in order. The relatively low laser power, high scanning speed, small spreading thickness and low heat input were conducive to obtaining a cladding channel with better formability. Increasing laser power and scanning speed were both beneficial to improve the pitting corrosion resistance of the cladding channel. The better the formability of the cladding channel, the better the pitting corrosion resistance.
-
Keywords:
- fuel cell /
- bipolar plate /
- laser cladding /
- corrosion resistance
-
-
[1] 张嘉波,唐普洪,许来涛,等.质子交换膜燃料电池金属双极板制备工艺研究进展[J].轻工机械,2016,34(6):102-106. [2] 吴俊峰,王匀,朱凯,等.微型燃料电池304不锈钢双极板累积成形研究[J].锻压技术,2014,39(4):47-50. [3] 张丽丽,王开坤.PEMFC金属双极板冲压成形数值模拟与实验[J].精密成形工程,2017,9(6):163-169. [4] 王蕾.PEMFC双极板磁脉冲成形研究[D].哈尔滨:哈尔滨工业大学,2011. [5] JIN C K,KANG C G.Fabrication process analysis and experimental verification for aluminum bipolar plates in fuel cells by vacuum die-casting[J].Journal of Power Sources,2011,196(20):8241-8249.
[6] DAWSON R J,PATEL A J,RENNIE A E W,et al.An investigation into the use of additive manufacture for the production of metallic bipolar plates for polymer electrolyte fuel cell stacks[J].Journal of Applied Electrochemistry,2015,45(7):637-645.
[7] YANG G Q,MO J K,KANG Z Y,et al.Additive manufactured bipolar plate for high-efficiency hydrogen production in proton exchange membrane electrolyzer cells[J].International Journal of Hydrogen Energy,2017,42(21):14734-14740.
[8] YANG G Q,YU S L,MO J K,et al.Bipolar plate development with additive manufacturing and protective coating for durable and high-efficiency hydrogen production[J].Journal of Power Sources,2018,396:590-598.
[9] LYONS K S,GOULD B D.Lightweight titanium metal bipolar plates for PEM fuel cells[J].Materials Science Forum,2016,879:613-618.
[10] CANO-LÓPEZ J A,ORTEGA-DÍAZ D,DUARTE-MOLLER A,et al.3D-printed current collector plates:Simulation and performance evaluation in a mini fuel cell[J].Fuel Cells,2018,18(6):782-788.
[11] LYONS B,BATALOV M,MOHANTY P,et al.Rapid prototyping of PEM fuel cell bi-polar plates using 3D printing and thermal spray deposition[C]//16th Solid Freeform Fabrication Symposium.Austin,US:University of Texas at Austin,2005,446- 457.
[12] LEON C P D,HUSSEY W,FRAZAO F,et al.The 3D printing of a polymeric electrochemical cell body and its characterisation[J].Chemical Engineering Transactions,2014,41:1-6.
[13] DUDEK P,RA AZ＇G NIAK A,LIS B.Rapid prototyping methods for the manufacture of fuel cells[J].E3S Web of Conferences,2016,10:00127.
[14] JANG J H,JOO B D,MUN S M,et al.Micropatterning of a bipolar plate using direct laser melting process[J].AIP Conference Proceedings,2010,1252:1233-1238.
[15] 潘琰峰,沈以赴,顾冬冬,等.316不锈钢粉末直接激光烧结的球化效应[J].中国机械工程,2005,16(17):1573-1576. 欢迎来稿欢迎订阅欢迎刊登广告
