Influence of Lubrication Condition and Cylinder Liner Material on Friction and Wear Characteristics of Piston Ring-Cylinder Liner
-
摘要: 在润滑油中未添加和添加质量分数0.1%MoS2润滑条件下，对YH31合金铸铁活塞环和不同材料（高硼铜铸铁和铬钼铝铸铁）缸套进行摩擦磨损试验，研究了润滑条件和缸套材料对摩擦因数、体积磨损量和磨损表面形貌的影响，分析了磨损机制。结果表明：MoS2的添加可以缩短活塞环与高硼铜铸铁缸套的磨合时间，延长稳定磨损时间，降低摩擦因数，减小体积磨损量；摩擦副表面磨痕较未添加MoS2润滑条件下细而浅，且未出现裂纹。在未添加MoS2润滑条件下，活塞环与铬钼铝铸铁缸套对磨比与高硼铜铸铁缸套对磨更早进入稳定磨损阶段，但稳定磨损持续时间较短，平均摩擦因数有所增大，体积磨损量大幅增加；活塞环的磨损机制均为抛光磨损，高硼铜铸铁缸套和铬钼铝铸铁缸套的磨损机制分别为磨粒磨损+疲劳磨损和磨粒磨损。Abstract: Friction and wear tests were conducted on YH31 alloy cast iron piston ring and cylinder liner of different materials (high boron copper cast iron and CrMoAl cast iron)under lubrication conditions of lubricating oil without and adding 0.1wt% MoS2.Influence of the lubrication condition and cylinder liner material on the friction coefficient, volumetric wear loss and wear surface morphology was studied, and the wear mechanism was analyzed.The results show that adding MoS2 shortened the running in period of the piston ring and high boron copper cast iron cylinder liner, prolonged the stable wear period, decreased the friction coefficient and reduced the volumetric wear loss; the wear marks on the rubbing pair surfaces were finer and more shallow than those under the lubrication condition without MoS2, and no cracks were found.Under the lubrication condition without MoS2, the piston ring matched with CrMoAl cast iron cylinder liner entered the stable wear stage earlier than that matched high boron copper cast iron cylinder liner, but the stable wear stage lasted shortly, the average friction coefficient increased, and the volumetric wear loss increased greatly.The wear mechanism of the piston ring was polishing wear; the high boron copper cast iron and CrMoAl cast iron cylinder liner had abrasive wear+fatigue wear and abrasive wear mechanisms, respectively.
-
Keywords:
- piston ring /
- cylinder liner /
- rubbing pair /
- wear /
- surface morphology
-
-
[1] KAPSIZ M,DURAT M,FICICI F.Friction and wear studies between cylinder liner and piston ring pair using Taguchi design method[J].Advances in Engineering Software,2011,42(8):595-603.
[2] 胡勇,屈盛官,李彬,等.不同表面织构对柴油机缸套-活塞环摩擦磨损性能的影响[J].润滑与密封,2013,38(4):57-62. HU Y,QU S G,LI B,et al.Effects of different surface textures on friction and wear performance of diesel cylinder liner-piston ring[J].Lubrication Engineering,2013,38(4):57-62.
[3] 何星,李若亭,毛杰键,等.环境与工况对柴油机缸套-活塞环磨损的影响[J].润滑与密封,2020,45(1):106-112. HE X,LI R T,MAO J J,et al.Influence of environment and working conditions on the wear of diesel engine cylinder liner and piston ring[J].Lubrication Engineering,2020,45(1):106-112.
[4] TUNG S C,MCMILLAN M L.Automotive tribology overview of current advances and challenges for the future[J].Tribology International,2004,37(7):517-536.
[5] 朱峰,王增全,王建平,等.合金铸铁缸套与PVD(CrN)活塞环配对时缸套磨损机理[J].内燃机学报,2014,32(5):474-479. ZHU F,WANG Z Q,WANG J P,et al.Wear mechanism of alloy cast iron cylinder liner coupled with PVD(CrN)piston ring[J].Transactions of CSICE,2014,32(5):474-479.
[6] 周龙,白敏丽,吕继组.结构参数对活塞环-气缸套润滑摩擦性能影响的数值模拟[J].内燃机学报,2012,30(5):796-801. ZHOU L,BAI M L,LÜ J Z.Numerical simulation into influence of structural parameters on lubrication and friction performance of piston ring-liner[J].Transactions of CSICE,2012,30(5):796-801.
[7] 唐令,何鹏飞,马国政,等.缸套-活塞环摩擦副表面性能强化研究进展[J].表面技术,2019,48(8):185-198. TANG L,HE P F,MA G Z,et al.Research progress in surface performance reinforcement of cylinder liner and piston ring friction pair[J].Surface Technology,2019,48(8):185-198.
[8] BUDZYSKI P,KAMISKI M,PYSZNIAK K.The influence of nitrogen ion implantation on the tribological properties of piston rings made of Hardox and Raex steels[J].IOP Conference Series:Materials Science and Engineering,2016,148:012044.
[9] 甄洪梅,宋吉林,王旭兰,等.柴油机气缸套-活塞环配副匹配特性研究[J].车用发动机,2014(3):46-49. ZHEN H M,SONG J L,WANG X L,et al.Matching characteristics of cylinder liner and piston ring pair for diesel engine[J].Vehicle Engine,2014(3):46-49.
[10] 江仁埔,郭智威,饶响,等.表面织构对缸套-活塞环摩擦学性能的影响[J].内燃机学报,2018,36(5):471-479. JIANG R P,GUO Z W,RAO X,et al.Influences of thread grooves surface texturing on tribological properties of cylinder liner-piston ring[J].Transactions of CSICE,2018,36(5):471-479.
[11] KOVALCHENKO A,AJAYI O,ERDEMIR A,et al.The effect of laser surface texturing on transitions in lubrication regimes during unidirectional sliding contact[J].Tribology International,2005,38(3):219-225.
[12] 林春元.二硫化钼的润滑机理[J].中国钼业,1993(2):40-46. LIN C Y.Lubrication mechanism of MoS2[J].China Molybdenum Industry,1993(2):40-46.
[13] ROSENTSVEIG R,GORODNEV A,FEUERSTEIN N,et al.Fullerene-like MoS2 nanoparticles and their tribological behavior[J].Tribology Letters,2009,36(5):175.
[14] HSU C H,SHY Y H,YU Y H,et al.Effect of austempering heat treatment on fracture toughness of copper alloyed gray iron[J].Materials Chemistry and Physics,2000,63(1):75-81.
[15] 华希俊,王皓,解玄,等.纳米固体润滑颗粒对微织构表面摩擦学性能的影响研究[J].机械制造,2019,57(7):84-89. HUA X J,WANG H,XIE X,et al.Effect of nano solid lubricating particles on tribological properties of micro textured surface[J].Machinery,2019,57(7):84-89.
[16] 李斌,谢凤,张蒙蒙,等.纳米二硫化钼作为润滑油添加剂的摩擦学性能研究[J].润滑与密封,2014,39(9):91-95. LI B,XIE F,ZHANG M M,et al.Study on tribological properties of nano-MoS2 as additive in lubricating oils[J].Lubrication Engineering,2014,39(9):91-95.
