Effect of Heat Input on Welding Thermal Cycle and Residual Stress of V-joints at Different Positions of Motor Bracket
-
摘要: 利用非线性有限元软件Marc建立含6处V型接头的管状电机支架模型，模拟研究了热输入对6处V型接头起弧端热循环以及焊缝区残余应力的影响。结果表明：热输入越高，起弧端温度峰值越高，接头在加热和冷却过程中的受热越均匀；热输入对焊缝前端和末端焊接残余应力的影响较小；对于焊缝中段，热输入越大，焊接残余应力越小，并且除了接头Ⅱ外，其他接头焊缝中段残余应力均表现为拉应力。Abstract: A tubular motor bracket model with six V-joints was established with a nonlinear finite element software Marc.The influence of heat input on the thermal cycle at the arcing end and the residual stress in welds of six V-joints were simulated and studied.The results show that the higher the heat input, the higher the peak temperature at the arcing end, and the more uniform the heat of the joint during heating and cooling processes.The heat input had a small effect on the welding residual stress at the front and end of the welds.For the middle of the welds, the greater the heat input, the smaller the welding residual stress; except for the joint II, the residual stresses in the middle of welds of other joints were all tensile stresses.
-
Keywords:
- tubular motor bracket /
- multilayer welding /
- V-joint /
- heat input /
- residual stress
-
-
[1] 赵雷,乔汉文,梁军,等.焊接参数对T92/S30432异种钢焊接接头室温力学性能的影响[J].机械工程材料,2015,39(1):32-38. ZHAO L,QIAO H W,LIANG J,et al.Effects of welding parameters on room temperature mechanical properties of T92/S30432 dissimilar welded joint[J].Materials for Mechanical Engineering,2015,39(1):32-38.
[2] 代雪佳,吴松林,成应晋,等.热输入对12MnNiCrMoV钢薄板焊接接头粗晶热影响区组织和性能的影响[J].机械工程材料,2016,40(11):63-66. DAI X J,WU S L,CHENG Y J,et al.Effect of welding heat input on microstructure and properties of CGHAZ of 12MnNiCrMoV steel sheets welded joint[J].Materials for Mechanical Engineering,2016,40(11):63-66.
[3] 王锡岭,李金燕,蔡俊,等.焊接热输入对核I级E2209-15焊条焊接2205双相不锈钢接头组织和性能的影响[J].金属功能材料,2019,26(6):37-43. WANG X L,LI J Y,CAI J,et al.Effect of welding heat input on microstructure and properties of 2205 duplex stainless steel joint welded by nuclear grade Ⅰ E2209-15 electrode[J].Metallic Functional Materials,2019,26(6):37-43.
[4] 杜全斌,路全彬,秦磊,等.热输入对5052铝合金焊接热影响区软化性能的影响[J].农机使用与维修,2020(1):28-30. DU Q B,LU Q B,QIN L,et al.Effect of heat input on the softening performance of 5052 aluminum alloy welding heat affected zone[J].Agricultural Mechanization Using & Maintenance,2020(1):28-30.
[5] 翟战江,曹洋,赵琳,等.热输入对DP600激光焊组织和力学性能的影响[J].钢铁研究学报,2019,31(6):582-591. ZHAI Z J,CAO Y,ZHAO L,et al.Effect of heat input on microstructure and mechanical properties of laser welded DP600 steel[J].Journal of Iron and Steel Research,2019,31(6):582-591.
[6] 肖波.热输入对S32750超级双相不锈钢TIG焊接接头腐蚀性能的影响研究[J].冶金与材料,2020,40(1):40-40. XIAO B.Research on influence of heat input on the corrosion properties of TIG welded joints of S32750 super duplex stainless steel[J].Metallurgy and Materials,2020,40(1):40-40.
[7] 杨林,熊建坤,余勇,等.大热输入对焊条电弧焊低合金钢力学性能的影响[J].材料导报,2019,33(增刊2):424-427. YANG L,XIONG J K,YU Y,et al.Effect of high heat input on mechanical properties of low alloy steel by electrode arc welding[J].Materials Reports,2019,33(S2):424-427.
[8] 冯祥利,王磊,刘杨.焊接材料及热输入对Q460钢厚板焊接接头拉伸性能的影响[J].机械工程材料,2019,43(3):1-6. FENG X L,WANG L,LIU Y.Effect of welding material and heat input on tensile property of welded joint of Q460 steel thick plate[J].Materials for Mechanical Engineering,2019,43(3):1-6.
[9] TSUYAMA T,NAKAI K,AKIYAMA M,et al.Effects of microstructure on mechanical property in weld metal formed with the hot-wire method applying ordinal CO2 gas shielded arc welding method[J].Tetsu-to-Hagane,2013,99(7):468-474.
[10] YAMAZAKI K,SUZUKI R,SHIMIZU H,et al.Spatter and fume reduction in CO2 gas-shielded arc welding by regulated globular transfer[J].Welding in the World,2012,56(9/10):12-19.
[11] 张利国,姬书得,方洪渊,等.焊接顺序对T形接头焊接残余应力场的影响[J].机械工程学报,2007,43(2):234-238. ZHANG L G,JI S D,FANG H Y,et al.Influence of welding sequence on welding stress of T joint[J].Chinese Journal of Mechanical Engineering,2007,43(2):234-238.
[12] 姬书得,方洪渊,刘雪松,等.焊接顺序对混流式水轮机转轮焊接应力的影响[J].机械工程学报,2005,41(8):224-227. JI S D,FANG H Y,LIU X S,et al.Effect of welding sequence on welding stress of francis turbine runner[J].Chinese Journal of Mechanical Engineering,2005,41(8):224-227.
