    马云海, 王延峰, 赵双群, 王苗苗. G115钢的高温持久性能和抗蒸汽氧化性能[J]. 机械工程材料, 2022, 46(2): 48-57. DOI: 10.11973/jxgccl202202008
    引用本文: 马云海, 王延峰, 赵双群, 王苗苗. G115钢的高温持久性能和抗蒸汽氧化性能[J]. 机械工程材料, 2022, 46(2): 48-57. DOI: 10.11973/jxgccl202202008
    MA Yunhai, WANG Yanfeng, ZHAO Shuangqun, WANG Miaomiao. High Temperature Endurance Property and Steam Oxidation Resistance of G115 Steel[J]. Materials and Mechanical Engineering, 2022, 46(2): 48-57. DOI: 10.11973/jxgccl202202008
    Citation: MA Yunhai, WANG Yanfeng, ZHAO Shuangqun, WANG Miaomiao. High Temperature Endurance Property and Steam Oxidation Resistance of G115 Steel[J]. Materials and Mechanical Engineering, 2022, 46(2): 48-57. DOI: 10.11973/jxgccl202202008

    G115钢的高温持久性能和抗蒸汽氧化性能

    High Temperature Endurance Property and Steam Oxidation Resistance of G115 Steel

    • 摘要: 在625~700 ℃和不同应力下对G115钢进行高温持久试验,研究其高温持久性能,并采用Larson-Miller(L-M)参数法外推获得该钢的1×105 h长时持久强度,另在650 ℃/27 MPa蒸汽参数下对G115钢进行2 000 h的氧化试验,研究氧化膜的表面及横截面形貌、物相组成及微区成分,并与T92钢进行了对比。结果表明:在富铜相的强化作用下,G115钢在650 ℃下的长时持久强度为82 MPa,明显高于T92钢的53 MPa; G115钢的抗蒸汽氧化性能优于T92钢,G115钢表面氧化膜的厚度约为102μm,小于T92钢表面氧化膜的厚度(约110μm);二者的氧化膜结构类似,外氧化层为粗大的柱状Fe3O4,内氧化层为Fe-Cr尖晶石和少量的Fe3O4,且外氧化层含有较多孔洞,剥落倾向较大。



      Abstract: The high temperature endurance test of G115 steel was carried out under different stresses at 625—700 ℃ to study its high temperature endurance performance, and the 1×105 h long-term endurance strength of the steel was extrapolated by the Larson-Miller(LM) parameter method. The oxidation test of G115 steel was carried out at 650 ℃/27 MPa steam parameter for 2 000 h, and the surface and cross-section morphology, phase composition and microarea composition of the oxide film were studied and compared with those of T92 steel. The results show that under the action of reinforcement of copper-rich phase, the long-term endurance strength of G115 steel at 650 ℃ was 82 MPa, which was significantly higher than 53 MPa of T92 steel. The steam oxidation resistance of G115 steel was better than that of T92 steel, and the thickness of oxide film on the surface of G115 steel was about 102 μm, which was smaller than about 110 μm of T92 steel. The oxide film structure of the two was similar. The outer oxide layer consisted of coarse columnar Fe3O4, and the inner oxide layer consisted of fine Fe-Cr spinel and a small amount of Fe3O4; the outer oxide layer had many holes, and the tendency of spalling was relatively large.



    /
