Effect of Pre- and Post-Weld Heat Treatment on Microstructure and Properties of 2195 Al-Li Alloy Double-Sided Friction Stir Welded Joints
-
摘要: 采用双面搅拌摩擦焊方法对6 mm厚2195铝锂合金板进行焊接,对比研究了焊前与焊后热处理(410 ℃×1 h退火+510 ℃×1 h固溶+155℃×1 h人工时效)对接头显微组织及力学性能的影响。结果表明:焊前热处理的接头焊核区晶粒呈细小等轴状,平均晶粒尺寸约为9.2μm,而焊后热处理的焊核区晶粒发生了异常长大现象,平均晶粒尺寸达到0.3 mm。焊前热处理接头的抗拉强度比焊后热处理条件下的接头高约4.7%,断后伸长率也得到明显提高,且焊前热处理接头的拉伸断裂方式为韧性断裂,焊后热处理接头的拉伸断裂方式为脆性断裂。焊前热处理接头的最大弯曲角度大于焊后热处理接头,具有良好的塑性变形能力。Abstract: 6 mm thick 2195 aluminum-lithium alloy plates were connected by double-sided friction stir welding. The effects of pre- and post-weld heat treatment(410 ℃×1 h annealing + 510 ℃×1 h solution and 155 ℃×1 h artificial aging) on the microstructure and mechanical properties of joints were compared and studied. The results show that the grains in the weld nugget area of the joint with pre-weld heat treatment were small and equiaxed, and the average grain size was about 9.2 μm. The grains in the weld nugget area with post-weld heat treatment grew abnormally, and the average grain size reached 0.3 mm. The tensile strength of the joint with pre-weld heat treatment was about 4.7% higher than that with post-weld heat treatment, and the percentage elongation after fracture was improved obviously. The tensile fracture mode of the joint with pre-weld heat treatment was ductile fracture, and that with post-weld heat treatment was brittle fracture. The maximum bending angle of the joint with pre-weld heat treatment was larger than the joint with post-weld heat treatment, indicating the joint had good plastic deformation ability.
-
Keywords:
- Al-Li alloy /
- friction stir welding /
- heat treatment /
- microstructure /
- mechanical property
-
-
[1] 李劲风,郑子樵,陈永来,等.铝锂合金及其在航天工业上的应用[J].宇航材料工艺,2012,42(1):13-19. LI J F,ZHENG Z Q,CHEN Y L,et al.Al-Li alloys and their application in aerospace industry[J].Aerospace Materials & Technology,2012,42(1):13-19.
[2] 方文鹏,杜晓伟,潘庆军.新技术在铝锂合金焊接中的应用[J].现代焊接,2008(2):17-19. FANG W P,DU X W,PAN Q J.Application of new technology in aluminum-lithium alloy welding [J].Modern Welding Technology,2008(2):17-19.
[3] LEE H S,YOON J H,YOO J T,et al.Friction stir welding process of aluminum-lithium alloy 2195 [J].Procedia Engineering,2016,149:62-66.
[4] MISHRA R S,MA Z Y.Friction stir welding and processing[J].Materials Science and Engineering:R:Reports,2005,50(1/2):1-78.
[5] ZHANG D D,QU W Q,LV Q B,et al.Mechanical behaviour of Al-Li alloy joints by different friction stir welding parameters[J].Advanced Materials Research,2014,1051:799-807.
[6] WU Y,MAO H,YANG Q B,et al.Effect of welding parameters on defects and fracture behavior of friction stir welded 2195-T8 Al-Li alloy joints[J].Materials Science Forum,2018,913:182-189.
[7] 陈向荣,郑子樵,叶志豪,等.2099铝锂合金搅拌摩擦焊接头的微观组织[J].稀有金属材料与工程,2018,47(6):1786-1792. CHEN X R,ZHENG Z Q,YE Z H,et al.Microstructure characterization of friction stir welded 2099 Al-Li alloy[J].Rare Metal Materials and Engineering,2018,47(6):1786-1792.
[8] HATAMLEH O.The effects of laser peening and shot peening on mechanical properties in friction stir welded 7075-T7351 aluminum [J].Journal of Materials Engineering and Performance,2008,17(5):688-694.
[9] ZHANG J,FENG X S,GAO J S,et al.Effects of welding parameters and post-heat treatment on mechanical properties of friction stir welded AA2195-T8 Al-Li alloy[J].Journal of Materials Science & Technology,2018,34(1):219-227.
[10] GAO C,GAO R Q,MA Y.Microstructure and mechanical properties of friction spot welding aluminium-lithium 2A97 alloy[J].Materials & Design,2015,83:719-727.
[11] LIN Y,LU C G,WEI C Y,et al.Influences of friction stir welding and post-weld heat treatment on Al-Cu-Li alloy[J].Advanced Engineering Materials,2018,20(2):1700652.
[12] 戴明亮,万心勇,彭熠,等.新型热处理工艺对搅拌摩擦焊接头性能的影响[J].西安交通大学学报,2017,51(8):136-141. DAI M L,WAN X Y,PENG Y,et al.Effects of a new post-weld heat treatment process on the properties of friction stir welded joints[J].Journal of Xi'an Jiaotong University,2017,51(8):136-141.
[13] CHEN K,GAN W,OKAMOTO K,et al.The mechanism of grain coarsening in friction-stir-welded AA5083 after heat treatment[J].Metallurgical and Materials Transactions A,2011,42(2):488-507.
[14] 刘大海,宗崇文,黎俊初,等.热处理对2A12铝合金搅拌摩擦焊板件时效成形的影响[J].材料热处理学报,2015,36(6):71-77. LIU D H,ZONG C W,LI J C,et al.Effects of heat treatment on creep age forming formability of friction stir welded 2A12 aluminum alloy sheet[J].Transactions of Materials and Heat Treatment,2015,36(6):71-77.
[15] 刘国光,徐韦锋,姬浩.旋转速度对铝合金搅拌摩擦焊接头弯曲性能的影响[J].电焊机,2015,45(5):112-116. LIU G G,XU W F,JI H.Influence of rotational speed on bending property of aluminum alloy friction stir welded joints[J].Electric Welding Machine,2015,45(5):112-116.
