Effect of Milling Parameters on Machined Surface Integrity of Nickel-Based Superalloy FGH4113A
-
摘要: 通过铣削试验分别研究了主轴转速(300,500,650,800,1 200 r·min-1)、铣削进给量(0.030,0.045,0.060,0.075,0.090 mm·r-1)和单道次铣削深度(0.20,0.35,0.50,0.65,0.80 mm)对FGH4113A镍基高温合金加工表面完整性的影响。结果表明:随着铣削进给量或单道次铣削深度的增大,加工表面的缺陷增多,表面粗糙度和硬度增大,表面残余应力逐渐由压应力转变成拉应力;随着主轴转速的增大,加工表面缺陷减少,表面粗糙度和硬度降低,残余压应力减小。在铣削速度超过800 r·min-1、单道次铣削深度小于0.35 mm、进给量控制在0.045 mm·r-1以下条件下,加工表面质量较好,表面粗糙度Ra在0.40 μm左右,残余应力为压应力,且无明显硬化层。Abstract: The effects of spindle speed (300, 500, 650, 800, 1 200 r·min-1), milling feed (0.030, 0.045, 0.060, 0.075, 0.090 mm·r-1) and single pass milling depth (0.20, 0.35, 0.50, 0.65, 0.80 mm) on the machined surface integrity of nickel-based superalloy FGH4113A were investigated by milling tests. The results show that with increasing milling feed or single pass milling depth, the defects on the machined surface, surface roughness and hardness increased, and the surface residual stress gradually changed from compressive stress to tensile stress. With increasing spindle speed, the machined surface defects, surface roughness, hardness and residual compressive stress all decreased. When the spindle speed exceeded 800 r·min-1, the single pass milling depth was less than 0.35 mm, and the milling feed was controlled below 0.045 mm·r-1, the machined surface had good quality with surface roughness Ra of about 0.40 μm, compressive residual stress and no obvious hardening layer existing.
-
Keywords:
- FGH4113A superalloy /
- milling /
- micromorphology /
- residual stress /
- surface roughness /
- hardness
-
-
[1] JIANG R,SONG Y D,REED P A.Fatigue crack growth mechanisms in powder metallurgy Ni-based superalloys:A review[J].International Journal of Fatigue,2020,141:105887.
[2] HENDERY M L,WHITTAKER M T,COCKINGS B J,et al.The effect of salt composition on the stress-free and corrosion-fatigue performance of a fine-grained nickel-based superalloy[J].Corrosion Science,2022,198:110113.
[3] 杜劲,刘战强,张入仁,等.镍基高温合金高速铣削加工表面完整性[J].中南大学学报(自然科学版),2012,43(7):2593-2600. DU J,LIU Z Q,ZHANG R R,et al.Surface integrity on high speed milling Ni-based superalloy[J].Journal of Central South University (Science and Technology),2012,43(7):2593-2600.
[4] LI Y S,ZOU B,SHI Z Y,et al.Wear patterns and mechanisms of sialon ceramic end-milling tool during high speed machining of nickel-based superalloy[J].Ceramics International,2021,47(4):5690-5698.
[5] ŞIRIN Ş,KIVAK T.Effects of hybrid nanofluids on machining performance in MQL-milling of Inconel X-750 superalloy[J].Journal of Manufacturing Processes,2021,70:163-176.
[6] LIAO Z R,XU D D,LUNA G G,et al.Influence of surface integrity induced by multiple machining processes upon the fatigue performance of a nickel based superalloy[J].Journal of Materials Processing Technology,2021,298:117313.
[7] 李子璇,雷学林,何云,等.铣削参数对高温合金GH4169低周疲劳性能影响研究[J].制造技术与机床,2021(7):114-119. LI Z X,LEI X L,HE Y,et al.Effect of different milling parameters on GH4169 low cycle fatigue life[J].Manufacturing Technology & Machine Tool,2021(7):114-119.
[8] ZHOU J H,REN J X,YAO C F.Multi-objective optimization of multi-axis ball-end milling Inconel 718 via grey relational analysis coupled with RBF neural network and PSO algorithm[J].Measurement,2017,102:271-285.
[9] GVNAN F,KVAK T,YLDRM Ç V,et al.Performance evaluation of MQL with Al2O3 mixed nanofluids prepared at different concentrations in milling of Hastelloy C276 alloy[J].Journal of Materials Research and Technology,2020,9(5):10386-10400.
[10] MUSFIRAH A H,GHANI J A,CHE HARON C H.Tool wear and surface integrity of Inconel 718 in dry and cryogenic coolant at high cutting speed[J].Wear,2017,376/377:125-133.
[11] 张阳,吴宝海,夏卫红,等.变切深工况下恒定切削力约束的多目标进给量优化方法[J].机械工程学报,2021,57(5):242-250. ZHANG Y,WU B H,XIA W H,et al.Multi-objective feed optimization with constant cutting force constraints under variable cutting depth[J].Journal of Mechanical Engineering,2021,57(5):242-250.
[12] 刘维伟,李锋,姚倡锋,等.GH4169高速铣削参数对表面粗糙度影响研究[J].航空制造技术,2012,55(12):87-90. LIU W W,LI F,YAO C F,et al.Effect of milling parameters on surface roughness in high speed milling GH4169[J].Aeronautical Manufacturing Technology,2012,55(12):87-90.
[13] 李学光,郭克,陈明泽,等.Inconel 718镍基高温合金铣削过程的数值模拟[J].福州大学学报(自然科学版),2021,49(4):485-490. LI X G,GUO K,CHEN M Z,et al.Numerical simulation of milling process of Inconel 718 nickel base superalloy[J].Journal of Fuzhou University (Natural Science Edition),2021,49(4):485-490.
[14] HOOD R,MORRIS J,SOO S L.Workpiece surface integrity when milling Udimet 720 superalloy[J].Procedia CIRP,2016,45:283-286.
[15] JIANG R,KARPASITIS N,GAO N,et al.Effects of microstructures on fatigue crack initiation and short crack propagation at room temperature in an advanced disc superalloy[J].Materials Science and Engineering:A,2015,641:148-159.
[16] GAO Y,STÖLKEN J S,KUMAR M,et al.High-cycle fatigue of nickel-base superalloy René 104(ME3):Interaction of microstructurally small cracks with grain boundaries of known character[J].Acta Materialia,2007,55(9):3155-3167.
[17] DENG R,LIU F,TAN L M,et al.Effects of scandium on microstructure and mechanical properties of RR1000[J].Journal of Alloys and Compounds,2019,785:634-641.
[18] TIAN T,HAO Z B,GE C C,et al.Effects of stress and temperature on creep behavior of a new third-generation powder metallurgy superalloy FGH100L[J].Materials Science and Engineering:A,2020,776:139007.
[19] HUANG H L,LIU G Q,WANG H,et al.Effect of cooling rate and resulting microstructure on tensile properties and deformation mechanisms of an advanced PM nickel-based superalloy[J].Journal of Alloys and Compounds,2019,805:1254-1259.
[20] 沈雪红,张定华,姚倡锋,等.钛合金切削加工表面完整性形成机制研究进展[J].航空材料学报,2021,41(4):1-16. SHEN X H,ZHANG D H,YAO C F,et al.Research progress on formation mechanism of surface integrity in titanium alloy machining[J].Journal of Aeronautical Materials,2021,41(4):1-16.
[21] LI Q,GONG Y D,CAI M,et al.Research on surface integrity in milling Inconel718 superalloy[J].The International Journal of Advanced Manufacturing Technology,2017,92(1):1449-1463.
[22] 杜随更,汪志斌,吕超,等.高温合金高速铣削表面形貌及组织研究[J].航空学报,2011,32(6):1156-1163. DU S G,WANG Z B,LU C,et al.Study on high-speed milling surface microstructure of superalloy[J].Acta Aeronautica et Astronautica Sinica,2011,32(6):1156-1163.
[23] 唐志涛,刘战强,艾兴.高速铣削加工铝合金表面残余应力研究[J].中国机械工程,2008,19(6):699-703. TANG Z T,LIU Z Q,AI X.Experimentation on the superficial residual stresses generated by high-speed milling aluminum alloy[J].China Mechanical Engineering,2008,19(6):699-703.
[24] LI W,WITHERS P J,AXINTE D,et al.Residual stresses in face finish turning of high strength nickel-based superalloy[J].Journal of Materials Processing Technology,2009,209(10):4896-4902.
[25] LU X H,JIA Z Y,LU Y J,et al.Predicting the surface hardness of micro-milled nickel-base superalloy Inconel 718[J].The International Journal of Advanced Manufacturing Technology,2017,93(1):1283-1292.
[26] SONG W G,LIU Z Q,YAO G H,et al.Effect of workpiece work hardening on machined surface topography generated in two-step milling process[J].Journal of Manufacturing Processes,2022,77:348-360.
