Effect of Grain Size on Low Cycle Fatigue Behavior and Microstructure after Fatigue of IF Steel
-
摘要: 通过850,950 ℃退火制备得到平均晶粒尺寸分别为40,210 μm的IF钢,研究了晶粒尺寸对其低周疲劳行为和疲劳后显微组织的影响。结果表明:在疲劳循环过程中,细晶试验钢的初始平均峰值应力高于粗晶试验钢,随着循环次数增加,2种试验钢的平均峰值应力趋于相近;细晶试验钢始终表现为循环加工硬化,粗晶试验钢表现为初始循环硬化、循环饱和和二次循环硬化。经400周次疲劳循环后,细晶试验钢的显微组织由尺寸相近且分布均匀的位错胞组成,粗晶试验钢的显微组织主要由宏观驻留滑移带(Macro-PSB)和位错胞组成,Macro-PSB中包含较为细小的位错胞;粗晶试验钢具有较高的位错密度及相对显著的组织不均匀性。Abstract: IF steels with average grain size of 40 μm and 210 μm were prepared by annealing at 850 ℃ and 950 ℃, respectively. The effects of the grain size on the low-cycle fatigue behavior and the microstructure after fatigue were investigated. The results show that during fatigue cycle, the initial average peak stress of the fine-grained test steel was higher than that of the coarse-grained test steel. The average peak stress of the two test steels tended to be equal with increasing number of cycles. The fine-grained test steel always showed cyclic work hardening during fatigue, while the coarse-grained test steel showed initial cycle hardening, cycle saturation and secondary cycle hardening. After 400 fatigue cycles, the microstructure of the fine-grained test steel was composed of similarly sized and uniformly distributed dislocation cells, while the microstructure of the coarse-grained test steel was mainly composed of macro-persistent slip band (Macro-PSB) and dislocation cells. The Macro-PSB contained relatively small dislocation cells. The coarse-grained test steel had higher dislocation density and relatively significant structural heterogeneity.
-
Keywords:
- IF steel /
- grain size /
- microstructure /
- low cycle fatigue behaviour
-
-
[1] 宋凤明,温东辉,李自刚,等.低屈服点钢的发展及应用[J].热加工工艺,2008,37(6):85-88. SONG F M,WEN D H,LI Z G,et al.Application and development of low yield point steel[J].Hot Working Technology,2008,37(6):85-88.
[2] SAEKI E,SUGISAWA M,YAMAGUCHI T,et al.Mechanical properties of low yield point steels[J].Journal of Materials in Civil Engineering,1998,10(3):143-152.
[3] THOMPSON A W,BACKOFEN W A.The effect of grain size on fatigue[J].Acta Metallurgica,1971,19(7):597-606.
[4] HANLON T,KWON Y N,SURESH S.Grain size effects on the fatigue response of nanocrystalline metals[J].Scripta Materialia,2003,49(7):675-680.
[5] LAWSON L,CHEN E Y,MESHII M.Near-threshold fatigue:A review[J].International Journal of Fatigue,1999,21:15-34.
[6] MUÑOZ J A,HIGUERA O F,CABRERA J M.High cycle fatigue of ARMCO iron severely deformed by ECAP[J].Materials Science and Engineering:A,2017,681:85-96.
[7] KOBAYASHI S,YANG W T,TOMOBE Y,et al.Low-angle boundary engineering for improving high-cycle fatigue property of 430 ferritic stainless steel[J].Journal of Materials Science,2020,55(22):9273-9285.
[8] ROLIM LOPES L C,CHARLIER J.Effect of grain size and intergranular stresses on the cyclic behaviour of a ferritic steel[J].Materials Science and Engineering:A,1993,169(1/2):67-77.
[9] SAWAI T, MATSUOKA S, TSUZAKI K. Low- and high-cycle fatigue properties of ultrafine-grained low carbon steels[J]. Tetsu-to-Hagane, 2003, 89(6): 726-733.
[10] MAGNIN T,RAMADE C,LEPINOUX J,et al.Low-cycle fatigue damage mechanisms of F.c.c. and B.c.c. polycrystals:Homologous behaviour?[J].Materials Science and Engineering:A,1989,118:41-51.
[11] SANGID M D.The physics of fatigue crack initiation[J].International Journal of Fatigue,2013,57:58-72.
[12] STANZL-TSCHEGG S,SCHÖNBAUER B.Near-threshold fatigue crack propagation and internal cracks in steel[J].Procedia Engineering,2010,2(1):1547-1555.
[13] SHIH C C,HO N J,HUANG H L.Dislocation evolution in interstitial-free steel during fatigue near the endurance limit[J].Journal of Materials Science,2010,45(3):818-823.
[14] SHIH C C,HO N J,HUANG H L.The study of fatigue behaviors and dislocation structures in interstitial-free steel[J].Metallurgical and Materials Transactions A,2010,41(8):1995-2001.
[15] SHIH C C,YEH D H,HO N J,et al.The study of crack-propagation behaviors and dislocation structures in cyclically deformed polycrystalline IF steel[J].Materials Science and Engineering:A,2011,528(21):6381-6386.
[16] KUMAGAI M,YOKOYAMA R.Characterization of microstructures by X-ray diffraction line profile analysis[J].Journal of the Society of Materials Science,Japan,2020,69(3):277-283.
[17] TAKEBAYASHI S,KUNIEDA T,YOSHINAGA N,et al.Comparison of the dislocation density in martensitic steels evaluated by some X-ray diffraction methods[J].ISIJ International,2010,50(6):875-882.
[18] MASUMURA T,URANAKA S,MATSUDA K,et al.Analysis of dislocation density by direct-fitting/modified Williamson-Hall (DF/mWH) method in tempered low-carbon martensitic steel[J].Tetsu-to-Hagane,2020,106(11):826-834.
[19] SHINTANI T,MURATA Y.Evaluation of the dislocation density and dislocation character in cold rolled Type 304 steel determined by profile analysis of X-ray diffraction[J].Acta Materialia,2011,59(11):4314-4322.
[20] POLÁK J,DEGALLAIX S,DEGALLAIX G.The role of cyclic slip localization in fatigue damage of materials[J].Le Journal De Physique IV,1993,3:679-684.
[21] JOHNSTON T L,FELTNER C E.Grain size effects in the strain hardening of polycrystals[J].Metallurgical and Materials Transactions B,1970,1(5):1161-1167.
[22] GREULICH F,MURR L E.Effect of grain size,dislocation cell size and deformation twin spacing on the residual strengthening of shock-loaded nickel[J].Materials Science and Engineering,1979,39(1):81-93.
[23] CUDDY J,NABIL BASSIM M.Study of dislocation cell structures from uniaxial deformation of AISI 4340 steel[J].Materials Science and Engineering:A,1989,113:421-429.
[24] DODARAN M,KHONSARI M M,SHAO S.Critical operating stress of persistent slip bands in Cu[J].Computational Materials Science,2019,165:114-120.
[25] KRUML T,POLÁK J.Fatigue softening of X10CrAl24 ferritic steel[J].Materials Science and Engineering:A,2001,319/320/321:564-568.
