Effect of Aging Temperature and Time on Structure and Properties of A356 Aluminum Alloy under Low Intensity Pulse Magnetic Field
-
摘要: 对A356铝合金进行T6热处理,在时效时施加33 mT低强度脉冲磁场,研究了时效温度(175,185 ℃)和时效时间(50,60,70 min)对A356铝合金显微组织和力学性能的影响。结果表明:在脉冲磁场作用下时效后,A356铝合金的二次枝晶间距随时效温度升高或时效时间延长而减小,共晶硅的长径比随时效时间延长先减小后增大;时效温度为185 ℃时共晶硅的直径和长径比较175 ℃时有所增大,但其数量减少;在脉冲磁场作用下时效后,A356铝合金的抗拉强度和屈服强度随时效时间延长或时效温度升高而增大;A356铝合金的热处理工艺可改进为540 ℃固溶60 min+175 ℃时效70 min,时效时施加33 mT脉冲磁场,该工艺处理后铝合金的拉伸性能满足使用要求。Abstract: T6 heat treatment was conducted on A356 aluminum alloy, whose aging process was carried out under 33 mT low intensity pulse magnetic field. The effects of aging temperature (175,185 ℃) and aging time (50, 60, 70 min) on the microstructure and mechanical properties of A356 aluminum alloy were studied. The results show that after aging under pulse magnetic field, the secondary dendrite spacing of A356 aluminum alloy decreased with the increase of aging temperature or aging time, and the aspect ratio of eutectic silicon decreased first and then increased with the increase of aging time. The size and aspect ratio of eutectic silicon at 185 ℃ aging temperature were higher than those at 175 ℃, but the quantity decreased. After aging under pulse magnetic field, the tensile strength and yield strength of A356 aluminum alloy increased with the increase of aging time or aging temperature. The improved heat treatment process for A356 aluminum alloy was solid solution at 540 ℃ for 60 min+aging at 175 ℃ for 70 min, and during aging applying 33 mT pulse magnetic field. Treated by this process, the tensile properties of the aluminum alloy met the reguirements.
-
-
[1] COLOMBO M,GARIBOLDI E,MORRI A.Er addition to Al-Si-Mg-based casting alloy:Effects on microstructure,room and high temperature mechanical properties[J].Journal of Alloys and Compounds,2017,708:1234-1244.
[2] QIU K Q,WANG R C,PENG C,et al.Effect of individual and combined additions of Al-5Ti-B,Mn and Sn on sliding wear behavior of A356 alloy[J].Transactions of Nonferrous Metals Society of China,2015,25:3886-3892.
[3] TSAI Y C,CHOU C Y,LEE S L,et al.Effect of trace La addition on the microstructures and mechanical properties of A356(Al-7Si-0.35Mg) aluminum alloys[J].Journal of Alloys and Compounds,2009,487:157-162.
[4] 王晨,姜文勇,冯义成,等.脉冲磁场对Al-12.6Si-1Cu合金组织的影响[J].特种铸造及有色合金,2016,36(3):302-305. WANG C,JIANG W Y,FENG Y C,et al.Effect of pulsed magnetic field on microstructure of Al-12.6Si-1Cu alloy[J].Special Casting & Nonferrous Alloys,2016,36(3):302-305.
[5] 张磊,袁秀妹,尧军平.低压脉冲磁场对Al-12.4Si合金组织与力学性能的影响[J].特种铸造及有色合金,2013,33(11):1074-1077. ZHANG L,YUAN X M,YAO J P.Effects of low voltage pulsed magnetic field(LVPMF) on microstructure and mechanical properties of Al-12.4Si alloy[J].Special Casting & Nonferrous Alloys,2013,33(11):1074-1077.
[6] 李腾,傅明喜,陈斌,等.脉冲磁场处理对(Fe74Ga2P9.65B4.6Si3C6.75)98Nb2结构及性能的影响[J].热加工工艺,2018,47(10):79-81. LI T, FU M X, CHEN B, et al. Effects of pulse magnetic field treatment on structure and property of (Fe74Ga2P9.65B4.6Si3C6.75)98Nb2[J].Hot Working Technology,2018,47(10):79-81.
[7] 赵作福,刘亮,齐锦刚,等.脉冲磁场作用下Al-5%Cu合金的时效机理[J].金属热处理,2016,41(5):113-116. ZHAO Z F,LIU L,QI J G,et al.Aging mechanism of Al-5%Cu alloy under pulse magnetic field[J].Heat Treatment of Metals,2016,41(5):113-116.
[8] 师亚洲,逯广平,高翌,等.脉冲磁场处理对7075铝合金性能及组织的影响[J].金属热处理,2021,46(9):159-164. SHI Y Z,LU G P,GAO Y,et al.Effect of pulsed magnetic field treatment on properties and microstructure of 7075 aluminum alloy[J].Heat Treatment of Metals,2021,46(9):159-164.
[9] 白庆伟,麻永林,邢淑清,等.可控电磁能(CEME)时效处理下Al-Zn-Mg-Cu合金的析出及强化机理研究[J].材料导报,2021,35(20):20143-20148. BAI Q W,MA Y L,XING S Q,et al.Precipitation and strengthening mechanism of Al-Zn-Mg-Cu alloy under controllable electromagnetic energy (CEME) aging treatment[J].Materials Review,2021,35(20):20143-20148.
[10] ZHANG K C,LI H Z,LIANG X P,et al.Effect of aging time on discontinuous precipitates,continuous precipitates and mechanical properties of AZ80A magnesium alloy[J].Transactions of Nonferrous Metals Society of China,2022,32(9):2838-2851.
[11] 朱景川,来忠红.固态相变原理[M].北京:科学出版社,2010. ZHU J C,LAI Z H.Solid-state phase transition principle[M].Beijing:Science Press,2010. [12] 白英龙,吴冲浒,杨霞,等.实际初始WC颗粒尺寸选择的LSW理论分析[J].粉末冶金材料科学与工程,2012,17(2):139-146. BAI Y L,WU C H,YANG X,et al.LSW theory analysis on size selection for initial WC particles[J].Materials Science and Engineering of Powder Metallurgy,2012,17(2):139-146.
[13] ZHU M,JIAN Z Y,YANG G C,et al.Effects of T6 heat treatment on the microstructure,tensile properties,and fracture behavior of the modified A356 alloys[J].Materials and Design,2012,36:243-249.
[14] ZHAO Z X,WU R Q,WANG B,et al.Effects of aging on the microstructure and properties of 7075 Al sheets[J].Materials,2020,13(18):4022-4022.
