Influence of Friction Force Between Anti-buckling Device and Specimen on Tensile and Compression Fatigue Life of Sheet
-
摘要: 采用TC4钛合金薄板防屈曲装置,在不同扭矩(1.5~2.5 N·m)和不同应变水平(0.25%~1.0%)下对SAPH440钢薄板试样进行拉压疲劳试验,研究了摩擦力对薄板试样疲劳寿命的影响,验证了防屈曲装置的适用性。结果表明:在以弹性应变为主导的低应变水平(0.25%)下,试样的疲劳寿命随摩擦力的增大而略微降低;在以塑性应变为主导的中高应变水平(0.5%~1.0%)下,试样的疲劳寿命随摩擦力的增大而增大;应变水平为0.25%,0.5%时试样裂纹扩展区中段疲劳辉纹间距均值分别为0.45,0.86 μm,随着应变水平继续增大,疲劳辉纹变得不明显,出现了较为明显的二次裂纹。Abstract: Tensile and compressive fatigue tests were carried out on SAPH440 steel sheet specimen with TC4 titanium alloy sheet anti-buckling device under different torques (1.5-2.5 N·m) and different strain levels (0.25%-1.0%). The effect of friction force on the fatigue life of the sheet specimen was studied, and the applicability of the anti-buckling device was verified. The results show that under the low strain level (0.25%) dominated by elastic strain, the fatigue life of the specimen decreased slightly with the increase of friction force. Under the medium and high strain levels (0.5%-1.0%) dominated by plastic strain, the fatigue life of the specimen increased with the increase of friction force. When the strain levels were 0.25% and 0.5%, the average distance between fatigue striations in the middle section of the crack propagation zone of the specimen was 0.45 μm and 0.86 μm, respectively. As the strain level continued to increase, the fatigue striations became less obvious, and more obvious secondary cracks appeared.
-
-
[1] 孙孝央,王泽华,周泽华,等.金属材料疲劳寿命评估的研究现状[J].机械工程材料,2017,41(2):1-7. SUN X Y,WANG Z H,ZHOU Z H,et al.Research status of fatigue life assessment of metal materials[J].Materials for Mechanical Engineering,2017,41(2):1-7.
[2] 孙晓冉,宋月,谷秀锐,等.汽车用SPHC热轧薄钢板的低周疲劳特性[J].机械工程材料,2021,45(4):57-60. SUN X R,SONG Y,GU X R,et al.Low cycle fatigue characteristics of SPHC hot-rolled steel sheet for automobile[J].Materials for Mechanical Engineering,2021,45(4):57-60.
[3] 兰天,杨凤鹏,李博林.SAPH440汽车薄板高低周疲劳特性试验研究[J].力学季刊,2016,37(3):559-564. LAN T,YANG F P,LI B L.Experimental study on high and low fatigue properties of automobile sheet SAPH440[J].Chinese Quarterly of Mechanics,2016,37(3):559-564.
[4] 闻邦椿.现代机械设计实用手册[M].北京:机械工业出版社,2015. WEN B C.Modern mechanical design practical guide[M].Beijing:China Machine Press,2015.
[5] 朱亦钢.一种用于金属薄板轴向拉压疲劳试验的防弯夹具[J].实验力学,2005,20(2):241-247. ZHU Y G.A research for thin metal sheet fatigue test under tension-compression loading[J].Journal of Experimental Mechanics,2005,20(2):241-247.
[6] 陈云霞,杨旋,李创.车身薄板疲劳试验装置及测试方法:102735557A[P].2012-10-17. CHEN Y,YANG X,LI C.Fatigue test device for vehicle body thin plate,and test method thereof:102735557A[P].2012-10-17.
[7] CAO J A,LEE W,CHENG H S,et al.Experimental and numerical investigation of combined isotropic-kinematic hardening behavior of sheet metals[J].International Journal of Plasticity,2009,25(5):942-972.
[8] TONG C,WU J,HUA K,et al.Low-cycle fatigue life evaluation of buckling-restrained braces based on cumulative plastic deformation curves[J].Advances in Structural Engineering,2022,25(2):336-354.
[9] 苏少普,常文魁,陈先民.飞机典型壁板结构剪切屈曲疲劳试验与分析方法[J].航空学报,2022,43(5):225219. SU S P,CHANG W K,CHEN X M.Fatigue buckling test and analytical approach of aircraft typical panel structures[J].Acta Aeronautica et Astronautica Sinica,2022,43(5):225219.
[10] 苏洪英,刘仁东,芦延鹏,等.汽车薄板拉-压高周疲劳试样的形状和尺寸选取[J].理化检验(物理分册),2021,57(10):27-31. SU H Y,LIU R D,LU Y P,et al.Shape and size selection of tension-compression high cycle fatigue specimens for automobile sheet[J].Physical Testing and Chemical Analysis (Part A:Physical Testing),2021,57(10):27-31.
[11] HU Y N,WU S C,WITHERS P J,et al.The effect of manufacturing defects on the fatigue life of selective laser melted Ti-6Al-4V structures[J].Materials & Design,2020,192:108708.
[12] PRASHANTH NAIK R,SAMATHAM M,PATANGAY V K,et al.Experimental study on the effect of annealing on fatigue life of SS 304 steels[J].International Journal of Scientific Research in Science,Engineering and Technology,2020:164-169.
[13] 机械工业理化检验人员技术培训和资格鉴定委员会.力学性能试验[M].北京:中国计量出版社,2008. Technical Training and Qualification Appraisal Committee for Physical and Chemical Inspection Personnel in Mechanical Industry.Mechanical property test[M].China Metrology Press,2008.
[14] 陶美娟.材料质量检测与分析技术[M].北京:中国质检出版社,2018. TAO M J.Material quality detection and analysis technology[M].Beijing:China Quality Inspection Press,2018.
[15] 刘冬,薛欢,杜丽影,等.冷轧薄板低周疲劳试验抗屈曲装置:205749099U[P].2016-11-30. LIU D,XUE H,DU L Y,et al.Flat cold rolled sheet hangs down anti bucking device of all fatigue test:205749099U[P].2016-11-30.
[16] DIETRICH L,SOCHA G,KOWALEWSKI Z L.Anti-buckling fixture for large deformation tension-compression cyclic loading of thin metal sheets[J].Strain,2014,50(2):174-183.
[17] KOWALEWSKI Z L,DIETRICH L,SOCHA G.Experimental investigation of thin brass sheets under tension-compression cyclic loading[J].Journal of Theoretical and Applied Mechanics,2015(3):757-757.
