Corrosion Fatigue Crack Growth Behavior of 13Cr-L80 Steel for High-Production Gas Well Tubing
-
摘要: 用复合磷酸盐完井液对取自13Cr-L80钢油管的紧凑拉伸试样进行预腐蚀处理,再进行疲劳裂纹扩展试验,通过分析疲劳裂纹扩展区形貌,研究了应力比(0.05~0.25)、加载载荷(10~14 kN)和载荷频率(0.6~1.8 Hz)对腐蚀疲劳裂纹扩展行为的影响。结果表明:随应力比增大,疲劳裂纹扩展区二次裂纹数量增多,13Cr-L80钢的裂纹扩展速率增大;随加载载荷增大,疲劳裂纹扩展区二次裂纹数量减少,裂纹扩展速率减小;载荷频率越高,疲劳裂纹扩展区二次裂纹数量越少,但裂纹尖端应变速率增大,裂尖变形更充分,导致裂纹扩展加快,试验中止时的循环次数减少。
-
关键词:
- 13Cr-L80钢油管 /
- 复合磷酸盐完井液 /
- 腐蚀疲劳 /
- 裂纹扩展试验
Abstract: Compact tensile specimens taken from 13Cr-L80 steel tubing were pre-corroded with composite phosphate completion fluid, and then was subjected to fatigue crack growth tests. By analyzing morphology of the fatigue crack growth zone, the effects of stress ratio (0.05-0.25), load (10-14 kN) and load frequency (0.6-1.8 Hz) on the corrosion fatigue crack growth behavior were studied. The results show that with increasing stress ratio, the number of secondary cracks in the fatigue crack growth zone increased, and the crack growth rate of 13Cr-L80 steel was improved. With increasing load, the number of secondary cracks in the fatigue crack growth zone decreased, and the crack growth rate was reduced. The higher the load frequency, the smaller the number of secondary cracks in the fatigue crack growth zone; but the strain rate at crack tips increased, and the crack tip deformation was more sufficient, leading to the fast crack growth, and the smaller number of cycles at test termination. -
-
[1] 吕祥鸿,刘乐乐,李健,等.高pH值完井液中钛合金管材的腐蚀行为研究[J].稀有金属材料与工程,2020,49(7):2326-2332. LYU X H,LIU L L,LI J,et al.Corrosion behavior of titanium alloy in high pH value completion fluid[J].Rare Metal Materials and Engineering,2020,49(7):2326-2332.
[2] 陈瑾闻.酸性环境中油井管钢裂纹扩展特性研究[D].西安:西安石油大学,2017. CHEN J W.The research on crack propagation of oil tubing in acidic environment[D].Xi'an:Xi'an Shiyou University,2017.
[3] 王文涛.金属材料腐蚀疲劳研究现状[J].轻工科技,2015,31(2):33-34. WANG W T.Research status of corrosion fatigue of metal materials[J].Light Industry Science and Technology,2015,31(2):33-34.
[4] PARIS P,ERDOGAN F.A critical analysis of crack propagation laws[J].Journal of Basic Engineering,1963,85(4):528-533.
[5] DONAHUE R J,CLARK H M,ATANMO P,et al.Crack opening displacement and the rate of fatigue crack growth[J].International Journal of Fracture Mechanics,1972,8(2):209-219.
[6] FORMAN R G,KEARNEY V E,ENGLE R M.Numerical analysis of crack propagation in cyclic-loaded structures[J].Journal of Basic Engineering,1967,89(3):459-463.
[7] MCEVILY A J,GROEGER J.On the threshold for fatigue crack growth[M]//Advances in Research on the Strength and Fracture of Materials.Amsterdam:Elsevier,1978:1293-1298.
[8] CUI W C.A state-of-the-art review on fatigue life prediction methods for metal structures[J].Journal of Marine Science and Technology,2002,7(1):43-56.
[9] ADEDIPE O,BRENNAN F,KOLIOS A.Corrosion fatigue load frequency sensitivity analysis[J].Marine Structures,2015,42:115-136.
[10] HUANG Y F,YE X B,HU B R,et al.Equivalent crack size model for pre-corrosion fatigue life prediction of aluminum alloy 7075-T6[J].International Journal of Fatigue,2016,88:217-226.
[11] 袁玲.气井完井管柱在完井液中断裂风险的防控技术[J].化学工程与装备,2020(2):221-222. YUAN L.Prevention and control technology of fracture risk of gas well completion string in completion fluid[J].Chemical Engineering & Equipment,2020(2):221-222.
[12] 梁秀娟,嵇海旭.30CrNi2MoV钢的腐蚀疲劳裂纹萌生与扩展行为研究[J].热加工工艺,2020,49(14):55-57. LIANG X J,JI H X.Research on corrosion fatigue crack initiation and propagation behavior of 30CrNi2MoV steel[J].Hot Working Technology,2020,49(14):55-57.
[13] 郑祥隆,谢旭,李晓章,等.钢丝裂纹扩展估算模型及其在预腐蚀疲劳寿命计算中的应用[J].土木工程学报,2017,50(3):101-107. ZHENG X L,XIE X,LI X Z,et al.Estimation model for steel wire crack propagation and its application in calculation of pre-corrosion fatigue life[J].China Civil Engineering Journal,2017,50(3):101-107.
[14] 王庆雷,李德才.疲劳裂纹扩展影响因素研究综述[J].机械工程师,2011(8):5-8. WANG Q L,LI D C.Review of research on the influencing factors on fatigue crack growth[J].Mechanical Engineer,2011(8):5-8.
[15] 王恒,刘肖,倪广县.应力比对E690高强钢腐蚀疲劳裂纹扩展影响的试验研究[J].热加工工艺,2019,48(10):79-82. WANG H,LIU X,NI G X.Experimental study on influence of stress ratio on corrosion fatigue crack propagation of E690 high strength steel[J].Hot Working Technology,2019,48(10):79-82.
[16] 范镒,苏豪展,陈凯,等.奥氏体不锈钢在海水环境中的腐蚀疲劳裂纹扩展行为[J].腐蚀与防护,2020,41(7):67-74. FAN Y,SU H Z,CHEN K,et al.Corrosion fatigue crack growth behavior of austenitic stainless steels in seawater environment[J].Corrosion & Protection,2020,41(7):67-74.
[17] 王鹏,王新虎,韩礼红,等.高温高压井油管完井液导致应力腐蚀开裂分析[J].金属热处理,2015,40(增刊1):191-194. WANG P,WANG X H,HAN L H,et al.Completion fluid induced stress corrosion cracking in HPHT well tubing[J].Heat Treatment of Metals,2015,40(S1):191-194.
[18] 卞宏友,翟泉星,李英,等.激光沉积修复GH738高温合金的组织与拉伸性能[J].中国激光,2017,44(10):1002003. BIAN H Y,ZHAI Q X,LI Y,et al.Microstructure and tensile properties of laser deposition repair GH738 superalloy[J].Chinese Journal of Lasers,2017,44(10):1002003.
[19] 宋威振.预置应力对铝合金疲劳裂纹扩展性能影响规律的研究[D].西安:长安大学,2018. SONG W Z.Research on effect of pre-stress on fatigue crack growth behavior of Al-alloy[D].Xi'an:Chang'an University,2018. [20] 翟战江,彭云,刘涛,等.应力比对25Cr2Ni2MoV钢疲劳裂纹扩展门槛值的影响[J].物理测试,2019,37(1):9-13. ZHAI Z J,PENG Y,LIU T,et al.Effect of stress ratio on fatigue crack propagation threshold value of 25Cr2Ni2MoV steel[J].Physics Examination and Testing,2019,37(1):9-13.
[21] 李树肖,李时磊,王西涛,等.热老化对核电厂一回路管道失效概率的影响[J].核动力工程,2013,34(6):138-142. LI S X,LI S L,WANG X T,et al.Effect of thermal aging on failure probability of a nuclear primary pipe[J].Nuclear Power Engineering,2013,34(6):138-142.
[22] 徐文志.气田封隔液高温高压条件下CO2腐蚀研究[J].长江大学学报(自科版),2015,12(31):37-40. XU W Z.The CO2 corrosion packing fluid for gas fields at HTHP[J].Journal of Yangtze University (Natural Science Edition),2015,12(31):37-40.
[23] LIU J,GUO X Q,WANG G R,et al.Bi-nonlinear vibration model of tubing string in oil & gas well and its experimental verification[J].Applied Mathematical Modelling,2020,81:50-69.
[24] 冯诚诚.Ti-TiN-Zr-ZrN多层膜残余应力及疲劳性能的研究[D].广州:华南理工大学,2015. FENG C C.Study on residual stress and fatigue properties of Ti-TiN-Zr-ZrN multilayer coatings[D].Guangzhou:South China University of Technology,2015. [25] 程靳,赵树山.断裂力学[M].北京:科学出版社,2006. CHENG J,ZHAO S S.Fracture mechanics[M].Beijing:Science Press,2006.
[26] 果冲. 不同腐蚀条件下4130X材料疲劳裂纹扩展速率研究及寿命预测[D].北京:北京工业大学,2020. GUO C.Research on fatigue crack growth rate and life prediction of 4130X material under different corrosion conditions[D].Beijing:Beijing University of Technology,2020.
