Effect of Pre-aging - Warm Forming Process Parameters on Microstructure and Properties of 7075 Aluminum Alloy
-
摘要:
对7075-T6铝合金进行了不同预时效温度（85,100,120 ℃）、预时效时间（0~32 h）、成形温度（150,200,250,300 ℃）的预时效-温成形处理,研究了工艺参数对合金组织和性能的影响,确定了最佳工艺参数。结果表明：随着预时效时间延长,7075铝合金晶粒尺寸无明显变化,析出相数量增加,硬度和强度均先增大后减小；相比预时效温度为100,120 ℃时,预时效温度为85 ℃时析出相的数量较少,尺寸较小,硬度和强度较大,断后伸长率较小；随着温成形温度升高,硬度和强度均减小；最佳预时效-温成形工艺参数为预时效温度85 ℃、预时效时间24 h、温成形温度150 ℃,此时合金综合性能最佳,抗拉强度和断后伸长率分别为T6态的95%和163%；成形后经180 ℃×30 min烘烤处理可提升其强度、降低塑性。
Abstract:The 7075 aluminum alloy was pre-aged and warm formed at different pre-aging temperatures (85, 100, 120 ℃) for different pre-aging times (0–32 h) and forming temperatures (150, 200, 250, 300 ℃). The effect of process parameters on the microstructure and properties of alloy was studied. The optimum process parameters were determined. The results show that with the extension of pre-aging time, the grain size of 7075 aluminum alloy had no obvious change, the amount of precipitated phase increased, and the hardness and strength increased first and then decreased. Compared with those at pre-aging temperature of 100, 120 ℃, the number and the size of precipitated phases were smaller, the hardness and strength were larger, and the percentage elongation after fracture was smaller at the pre-aging temperature of 85 ℃. The hardness and strength decreased with the increase of warm forming temperature. The optimum pre-aging-warm forming process parameters were listed as follows: pre-aging temperature of 85 ℃, pre-aging time of 24 h, and warm forming temperature of 150 ℃. At this time, the alloy had the best comprehensive properties, which had the tensile strength and percentage elongation after fracture were 95% and 163% of those of the 7075-T6 aluminum alloy, respectively. Baking at 180 ℃ for 30 min after forming could improve the strength and reduce the ductility.
-
Keywords:
- 7075 aluminum alloy /
- pre-aging /
- warm forming /
- baking
-
-
![]()
图 2 85 ℃下预时效不同时间并在150 ℃下温成形后7075铝合金的显微组织与晶粒尺寸
Figure 2. Microstructures and grain size of 7075 aluminum alloy after pre-aging at 85 ℃ for different times and warm forming at 150 ℃
![]()
图 3 不同温度下预时效24 h并在150 ℃下温成形后7075铝合金的显微组织
Figure 3. Microstructures of 7075 aluminum alloy after pre-aging at different temperatures for 24 h and warm forming at 150 ℃
![]()
图 4 不同温度预时效不同时间并在150 ℃下温成形后7075铝合金的力学性能
Figure 4. Mechanical properties of 7075 aluminum alloy after pre-aging at different temperatures for different times and warm forming at 150 ℃: (a) hardness; (b) tensile strength; (c) yield strength and (d) percentage elongation after fracture
![]()
图 5 不同温度下预时效不同时间并在150 ℃下温成形后7075铝合金的拉伸断口形貌
Figure 5. Tensile fracture morphology of 7075 aluminum alloy after pre-aging at different temperatures for different times and warm forming at 150 ℃
-
[1] MORI K I ,ABE Y. A review on mechanical joining of aluminium and high strength steel sheets by plastic deformation[J]. International Journal of Lightweight Materials and Manufacture,2018,1（1）：1-11. [2] KARBASIAN H ,TEKKAYA A E. A review on hot stamping[J]. Journal of Materials Processing Technology,2010,210（15）：2103-2118. [3] ZHENG K L ,POLITIS D J ,WANG L L ,et al. A review on forming techniques for manufacturing lightweight complex-shaped aluminium panel components[J]. International Journal of Lightweight Materials and Manufacture,2018,1（2）：55-80. [4] 马鸣图,毕祥玉,游江海,等. 铝合金汽车板性能及其应用的研究进展[J]. 机械工程材料,2010,34（6）：1-5. MA M T ,BI X Y ,YOU J H ,et al. Research progress of property and its application of aluminium alloy auto sheet[J]. Materials for Mechanical Engineering,2010,34（6）：1-5.
[5] 范子杰,桂良进,苏瑞意. 汽车轻量化技术的研究与进展[J]. 汽车安全与节能学报,2014,5（1）：1-16. FAN Z J ,GUI L J ,SU R Y. Research and development of automotive lightweight technology[J]. Journal of Automotive Safety and Energy,2014,5（1）：1-16.
[6] 张新明,邓运来,张勇. 高强铝合金的发展及其材料的制备加工技术[J]. 金属学报,2015,51（3）：257-271. ZHANG X M ,DENG Y L ,ZHANG Y. Development of high strength aluminum alloys and processing techniques for the materials[J]. Acta Metallurgica Sinica,2015,51（3）：257-271.
[7] 徐振海,单德彬. 车身制造中的铝合金板热处理-冲压一体化技术[J]. 材料科学与工艺,2018,26（3）：1-9. XU Z H ,SHAN D B. Heat treatment-stamping integrated techniques for aluminum alloy sheets in the automotive body manufacture[J]. Materials Science and Technology,2018,26（3）：1-9.
[8] XU X F ,ZHAO Y G ,WANG X D ,et al. The rapid age strengthening induced by Ag additions in 7075 aluminum alloy[J]. Materials Science and Engineering：A,2015,648：367-370. [9] 董宇,费文慧,王新宇,等. 7050合金电流场时效析出行为[J]. 材料热处理学报,2019,40（7）：26-32. DONG Y ,FEI W H ,WANG X Y ,et al. Aging precipitation behavior of 7050 alloy under applied current[J]. Transactions of Materials and Heat Treatment,2019,40（7）：26-32.
[10] KU M H ,HUNG F Y ,LUI T S ,et al. Enhanced formability and accelerated precipitation behavior of 7075 Al alloy extruded rod by high temperature aging[J]. Metals,2018,8（8）：648. [11] 吴思昕7075铝合金预时效-温成形工艺研究长春吉林大学2021吴思昕. 7075铝合金预时效-温成形工艺研究[D]. 长春：吉林大学,2021. WU S XStudy on pre-aging-warm forming process of 7075 aluminum alloyChangchunJilin University2021WU S X. Study on pre-aging-warm forming process of 7075 aluminum alloy[D]. Changchun：Jilin University,2021.
[12] MARLAUD T ,DESCHAMPS A ,BLEY F ,et al. Evolution of precipitate microstructures during the retrogression and re-ageing heat treatment of an Al-Zn-Mg-Cu alloy[J]. Acta Materialia,2010,58（14）：4814-4826. [13] 李红英,程勇胜,郑子樵. 时效制度对7475铝合金挤压件组织与性能的影响[J]. 中南工业大学学报（自然科学版）,2001,32（4）：394-397. LI H Y ,CHENG Y S ,ZHENG Z Q. Effects of aging on microstructure and properties of 7475 alloy extrusions[J]. Journal of Central South University（Science and Technology）,2001,32（4）：394-397.
