High-Temperature Properties and Microstructure of Argon-Arc Welded Joint of GH3230 Superalloy
-
摘要: 通过扫描电镜、高温拉伸试验机和高温蠕变试验机等对GH3230高温合金钨极氩弧焊接接头的显微组织和高温性能进行了研究。结果表明: 焊缝组织主要由平衡凝固γ-FeCrNiC镍基固溶体、少量的颗粒状γ′-Ni3Al和MC碳化物组成, 呈等轴树枝状; 热影响区的组织与母材的相当, 但晶粒更粗大; 焊接接头具有良好的高温性能, 其在927 ℃下的高温抗拉强度为244 MPa, 与母材的相当, 在927 ℃和62 MPa下的高温蠕变寿命为38.82 h, 高于母材的; 高温拉伸和高温蠕变试验后的接头断口形貌与母材的基本一致, 分别为韧窝型和沿晶断裂。
-
关键词:
- GH3230高温合金 /
- 氩弧焊 /
- 高温蠕变
Abstract: The high temperature properties and microstructure of GH3230 alloy argon arc welded joint were investigated by SEM, high temperature tensile test and high temperature creep test. The results indicate that the equiaxial dendritic microstructure of welded seam was made up of equilibrium frozen Ni based solid solution, γ-FeCrNiC, a little bit granular carbides, γ′-Ni3Al and MC.The microstructure in heat affected zone was the same as in the base metal, but grains in heat affected zone was bigger than in the base metal. The joint exhibited good high temperature properties with a tensile strength of 244 MPa at 927 ℃, as same as the base metal, and a creep life of 38.82 h at 927 ℃ and 62 MPa which was higher than the base metal. The fracture morphology of welded joints after high temperature tensile test and creep test were basically identical which were dimple and intergranular fracture, respectively.-
Keywords:
- GH3230 superalloy /
- argon-arc welding /
- high temperature creep
-
-
[1] HYDE T H, XIA L, BECKER A A. Prediction of creep failure in aeroenging materials under multi-axial stress states[J].International Journal of Mechanical Sciences, 1996, 38(4): 385-403. [2] HYDE T H, BECKER A A, SONG Y, et al. Failure estimation of TIG butt-welded Inco718 sheets at 620℃ under creep and plasticity conditions[J].Computational Materials Science, 2006, 35(1): 35-41. [3] 周海, 丁成钢, 胡飞, 等.不同电流下AZ31镁合金交流钨极氩弧焊焊接接头的显微组织与力学性能[J].机械工程材料, 2011, 35(5): 47-54. [4] MUNITZ A, COTLER C, STERN A, et al. Mechanical properties and microstructure of gas tungsten arc welded magnesium AZ91D plates[J].Materials Science and Engineering: A, 2001, 302: 68-73. [5] 尹丽香. TC4钛合金电子束焊接接头高温性能与组织[J].焊接学报, 2007, 28(10): 49-52. [6] HOPGOOD A A, MARTIN J W.The creep behaviour of a nickel-based single crystal superalloy[J].Materials Science and Engineering: A, 1986, 82: 27-36. [7] 《中国航空手册》编辑委员会. 中国航空材料手册[M].北京: 中国标准出版社, 2002.
