Finite Element Simulation of the Effect of Structure Parameters of Aluminium Alloy Lug Attachment on Its Fracture Characteristic
-
摘要: 建立了7000系列铝合金含孔边穿透裂纹斜耳片连接件的三维有限元模型, 模拟研究了单边裂纹与双边裂纹两种损伤模式下耳片外内径比值、斜切角、裂纹长度等结构参数对裂纹尖端I型应力强度因子KI值的影响规律。结果表明: 在相同等效裂纹无量纲长度下, 单边裂纹与双边裂纹两种损伤模式的裂尖KI值随裂纹扩展或斜切角增加的变化规律基本一致; 外内径比值大于2的耳片有利于进行损伤容限设计及检查; 在相同的裂纹长度下, 斜切角15°至25°左右的耳片裂纹扩展速率比直耳片的有明显下降。Abstract: The 3-D finite element model for 7000 series aluminium alloy lug attachment with through cracks was established to study the effects of the lug′s structure parameters such as ratio of outer radius to inside radius, bevel angle and crack length under two types of damage model of single-edge crack and double-edge crack, on I-type stress intensity factor KI by simulation. The results show that in the same equivalent crack dimensionless length the effects of crack growth and bevel angle on KI in the two types of damage model were basically accordant. Lugs with R2/R1>2 benefited the damage tolerance design and examination. For the lug with 15°-25° bevel angles, the value KI was obviously less than the straight lug′s at the same crack length.
-
-
[1] RIGBY R, ALIABADI M H. Stress intensity factors for cracks at attachment lugs[J].Engineering Failure Analysis, 1997, 4(2): 133-146. [2] 张树祥.任意角度受载的耳片强度分析[J].机械设计, 1992(1): 22-25. [3] 刁文琦.耳片接头的静强度可靠性分析与计算[J].飞机设计, 1993(1): 59-72. [4] 陈秀华.飞机平尾升降舵接头耳片承载能力分析与试验[J].计算机辅助工程, 2009, 18(1): 18-21. [5] WALKER C A, MCKELVIE J, HYZER J B. An analysis of residual stress patterns resulting from hole expansion in an infinite plate, a thick cylinder, and an asymmetric lug[J].Optics and Lasers in Engineering, 1997, 27(1): 75-87. [6] SATISH KUMAR K, DATTAGURU B, RAMAMURTHY T S. Analysis of a cracked lug loaded by an interference fit pin[J].International Journal of Mechanical Sciences, 1996, 38: 967-979. [7] Vogwell J. Failure in lug joints and plates with holes[J].Engineering Failure Analysis, 1995, 12(2): 129-135. [8] 黄其青.对称与非对称斜削耳片危险部位及应力强度因子的有限元分析[J].航空学报, 1998, 19(4): 466-470. [9] 伍黎明, 何宇廷, 安涛, 等. 斜耳片连接件应力强度因子表达式的计算研究[J].机械强度, 2013, 35(1): 83-88.
