S136不锈钢基体溅射氮化铬薄膜的硬度和接触角

王翠凤; 邱锡荣; 康爱军; 梁家豪; 黄文荣

S136不锈钢基体溅射氮化铬薄膜的硬度和接触角

1.
福建信息职业技术学院, 福州 350003
2.
高雄应用科技大学模具工程系, 高雄 80706
3.
东北特殊钢集团技术中心工模具钢研究室, 抚顺 113001

基金项目:

福建省教育厅科研项目(JA13380)

详细信息

作者简介:
王翠凤(1969-), 女, 辽宁阜新人, 副教授, 高级工程师, 硕士。

中图分类号: TG142.45
计量
- 文章访问数: 1
- HTML全文浏览量: 0
- PDF下载量: 1
出版历程
- 收稿日期: 2013-11-26
- 刊出日期: 2013-12-19

Hardness and Contact Angle of CrN Coating Sputtered on Matrix of S136 Stainless Steels

摘要

摘要: 在不同的S136不锈钢基体上溅射制备了氮化铬(CrN)薄膜, 通过接触角的测量、硬度测试、扫描电子显微镜观察及X射线衍射分析等方法研究了基材的组织、方向性、表面粗糙度、表面机械加工方法及溅射偏压对CrN薄膜接触角和硬度的影响。结果表明: 在溅射功率300 W、施加-120 V偏压、氩气和氮气流量比9∶1溅射条件下, 可得到Cr2N单相薄膜, 呈现(111)面择优取向; 溅射CrN薄膜显著提高S136不锈钢表面硬度和接触角; 溅射时施加负偏压的CrN薄膜接触角明显大于未施加的; 基材杂质少、碳化物细小、研磨后抛光、施加负偏压的纵向试样溅射CrN薄膜后硬度较高(1 177 HV)、接触角较大(98.77°)。
- CrN薄膜 /
- 接触角 /
- S136不锈钢
Abstract: CrN coating was prepared on the surface of different S136 stainless steels by sputtering. By means of contact angle measurement, hardness testing, scanning electron microscopy (SEM) and X-ray diffraction (XRD), effects of parameters such as microstructure, orientation, surface roughness, machining process and sputtering bias on the contact angle and hardness of CrN coating were studied. The experimental results indicate that single phase Cr2N coating with the preferred orientation of (111) plane was obtained by sputtering under conditions of 300 W, -120 V bias when the flow ratio of argon to nitrogen was 9∶1. The surface hardness and contact angle of S136 stainless steels were significantly improved after CrN sputtering. The contact angle of CrN coating sputtered with bias voltage was obviously larger than that without bias voltage. The longitudinal direction samples with less impurities and fine carbides, polished after grinded and sputtered with bias voltage, had higher hardness (1 177 HV) and larger contact angle (98.77°) after CrN sputtering.
- CrN film /
- contact angle /
- S136 stainless steel

HTML全文

参考文献(17)

[1]	POLCAR T, PARREIRA N M G, NOVáKN R. Friction and wear behavior of CrN coating at temperature up to 500 ℃[J].Surface and Coatings Technology, 2007, 201(9/11): 5228-5235.
[2]	PRADHAN S K, NOUVEAU C, VASIN A, et al. Deposition of CrN coatings by PVD methods for mechanical application[J].Surface and Coatings Technology, 2005, 200(1/4): 141-145.
[3]	XU J H, UMEHARA H, KOJIMA I. Effect of deposition parameters on composition, structures, density and topography of CrN films deposited by r.f. magnetron sputtering[J].Applide Surface Science, 2002, 201(1/4): 208-218.
[4]	HO W Y, HSU C H, HUNG D H, et al. Oxygen effect on the mechanical behaviors of Cr(N, O)/CrN double-layered coatings by cathodic arc evaporation[J].Surface and Coatings Technology, 2004, 188/189(11/12): 129-134.
[5]	OLAYA J J, RODIL S E, MUHL S, et al. Influence of the energy parameter on the microstructure of chromium nitride coatings [J].Surface and Coatings Technology, 2006, 200(1/4): 5743-5750.
[6]	FORNIS E, ESCOBAR GALINDO R, SNCHEZ O, et al. Growth of CrNx films by DC reactive magnetron sputtering at constant N2/Ar gas flow[J].Surface and Coatings Technology, 2006, 200(1/3): 6047-6053.
[7]	王翠凤, 邱锡荣, 赵乙璇, 等.直流磁控溅射法在PET基板上制备AZO薄膜[J].中国表面工程, 2012, 25(6): 53-60.
[8]	杨发展, 王世庆, 唐德礼, 等.直管磁过滤弧离子镀CrN涂层改善304不锈钢表面性能研究[J].真空科学与技术学报, 2011, 31(1): 67-70.
[9]	冶艳, 尚魁平, 鲍明东, 等.CrN硬质镀层对磨热固性塑料的摩擦学行为研究[J].表面技术, 2012, 31(1): 27-30.
[10]	刘清平, 曲敬信, 潘国顺.多弧离子镀(Ti, C r)N膜层工艺及性能 [J].机械工程材料, 2002, 26(3): 20-23.
[11]	CHOI H W, DAUSKARDT R H, LEE S C, et al. Characteristic of silver doped DLC films on surface properties and protein adsorption [J].Diamond & Related Materials, 2008, 17: 252-257.
[12]	黄正丰.氮气流量对CrN薄膜抗粘黏性影响的研究[D].高雄: 国立高雄第一科技大学, 2011.
[13]	王翠凤, 邱锡荣, 王珉玟, 等. 氧化锆微注射成形工艺参数[J].粉末冶金材料科学与工程, 2012, 17(6): 712-718.
[14]	MCKENZIE D R, YIN Y, MCFALL W D, et al. The orientation dependence of elastic strain energy in cubic crystals and its application to preferred orientation in titanium nitrides thin films[J]. Journal of Physics, 1996, 32(8): 5883-5890.
[15]	梁柔, 徐雪波, 鲍明东, 等.不同轰击能量下CrN 硬质薄膜的生长方式和择优取向变化[J].兵器材料与科学, 2011, 34(2): 73-76.
[16]	NAM K H, JUNG M J, HAN J G. A study on the high rate deposition of CrNx films with controlled microstructure by magnetron sputtering[J].Surface and Coatings Technology, 2000, 131(1/3): 222-227.
[17]	ERA H, IDE Y, NINO A, et al. TEM study on chromium nitride coatings deposited by reactive sputter method[J].Surface Coatings Technology, 2005, 194(2/3): 265-270.
