Preparation and Welding Properties of Amorphous Ni-Mo-P Filler Metal
-
摘要: 利用单辊极冷法制备了Ni78Mo14P8非晶合金钎料带, 采用XRD和DSC分析了钎料的物相组成和熔化特性, 并将其用于不同温度下(975, 1 000, 1 025, 1 050 ℃)不锈钢和20碳钢的瞬时液相焊, 对钎焊接头的抗剪强度和显微组织进行了分析。结果表明: 该镍钼磷钎料为单一的非晶态相, 其约化玻璃转变温度参数为0.54, 过冷液体区间为41 ℃, 具有良好的非晶形成能力; 随着钎焊温度升高, 钎焊接头的抗剪强度与焊缝区显微硬度都逐渐增大; 焊缝区的主要组织为FeNi固溶体和Mo2Ni6P3、Ni3P、Ni2P化合物组成的共晶组织。Abstract: The Ni78Mo14P8 amorphous alloy filler metal ribbon was prepared by single roller rapid solidification. The phase of filler metal was investigated by XRD, and the melting behaviour was investigated by DSC. The amorphous ribbon was used in transient liquid phase bonding between stainless steel and 20 carbon steel at 975, 1 000, 1 025, and 1 050 ℃. The shear strength and microstructure of the soldered joint was analyzed. The results show that the phase of Ni-Mo-P filler metal was single amorphous, the reduced glass transition temperature(trg) of Ni78Mo14P8 amorphous alloy was 0.54, and the supercooled liquid range (Δtx) was 41 ℃, indicating good amorphous formation ability. As brazing temperature increased, the shear strength of the brazed joint and the micro-hardness of the solder area also increased gradually. The microstructure of solder seam was FeNi solid solution phase and eutectic organization consisting of Mo2Ni6P3, Ni3P and Ni2P.
-
-
[1] 张启运, 庄鸿寿.钎焊手册[M]. 北京: 机械工业出版社, 2008, 217-218. [2] 俞伟元, 陈学定, 路文江, 等.瞬间液相焊非晶铜基钎料的制备及其性能研究[J].电焊机, 2008, 38(7): 9-11. [3] INOUE A, KOSHIBA H, ZHANG T, et al. Thermal and magnetic properties of Fe50Co7Ni7Zr10-xNbxB20 amorphous alloys with wide supercooled liquid range[J].Mater Trans J M, 1997, 38: 577-582. [4] 马立群, 王立民, 张涛, 等.Zr, Nb对Fe-B合金非晶形成能力的影响[J].金属学报, 1999, 35(6): 631-633. [5] 丁毅, 王小霞, 周栋, 等.高频感应加热钎焊工艺制备碳钢/不锈钢复合板接头的显微组织[J].机械工程材料, 2011, 35(9): 68-71. [6] TAKEUCHI A, INOUE A. Classification of bulk metallic glasses by atomic size difference, heat of mixing and period of constituent elements and its application to characterization of the main alloying element[J].Materials Transactions, 2005, 12: 2817-2829. [7] 邹家生, 许志荣, 蒋志国, 等.Ti-Zr-Ni-Cu非晶钎料[J].焊接学报, 2005, 26(10): 51-53. [8] 李维火.多元非晶形成及力学性能研究[D].上海: 上海大学, 2002. [9] INOUE A, GOOK J S. Multicomonent Fe-based glassy alloys with wide supercooled liquid region before crystallization[J].Mater Trans J M, 1995, 36: 1180-1183. [10] INOUE A, ZHANG T, ITOI T, et al. New Fe-Co-Ni-B amorphous alloys with wide supercooled liquid region and good softmagnetic properties[J].Mater Trans J M, 1997, 38: 359-362. [11] 陈忠宝.Ni-P钎料真空钎焊不锈钢接头性能及扩散行为的研究[D].兰州: 兰州理工大学, 2007. [12] 余伟元, 陈学定, 路文江, 等.快速凝固钎焊薄带[J].焊接技术, 2006, 35(3): 2-4.
