High Temperature Resistivity of Sr2Nb2O7 Ferroelectric Ceramics
-
摘要: 采用固相合成法制备了Sr2Nb2O7粉体并应用二步法织构烧结工艺制备得到Sr2Nb2O7陶瓷，研究了陶瓷的显微组织、物相组成以及电阻率随温度及时间的变化。结果表明：陶瓷为纯相，组织为板状晶粒，晶粒沿着加压方向取向良好；陶瓷的高温电阻率随温度的升高而下降，在800℃保温125 h时，垂直试样（其面法线方向垂直于加压方向）的电阻未发生退化；在980℃和1 000℃下，垂直试样均发生了电阻退化行为，且分别在保温20，1 h后出现了击穿现象；在1 000℃下，平行试样（其面法线方向平行于加压方向）因晶界数量较多，其电阻率退化时间较长。
-
关键词:
- Sr2Nb2O7铁电陶瓷 /
- 类钙钛矿层状结构 /
- 高温电阻率 /
- 晶粒取向
Abstract: Sr2Nb2O7 powder was prepared by solid-state reaction method, and then Sr2Nb2O7 ceramics were prepared by two-step textured sintering process. The microstructure, phase composition and the change of resistivity with temperature and time of the ceramics were studied. The results show that the ceramics had a pure phase. The structure was composed of plate-like grains and the grains were oriented well along the pressing direction. The high temperature resistivity of the ceramics decreased with the increase of temperature. During holding at 800℃ for 125 h, the resistance of the perpendicular samples (normal direction of the sample surface was perpendicular to the pressing direction) did not deteriorate. At 980℃ and 1 000℃, the perpendicular samples showed resistance degradation behavior, and the breakdown occurred after holding for 20 h and 1 h, respectively. At 1 000℃, the parallel sample (normal direction of the sample surface was parallel to the pressing direction) had relatively long degradation time of resistivity because of the relatively large number of grain boundaries. -
-
[1] TAKENAKA T, SAKATA K. Grain orientation effects on electrical properties of bismuth layer-structured ferroelectric Pb(1-x)(NaCe)x/2Bi4Ti4O15 solid solution[J]. Journal of Applied Physics, 1984, 55(4):1092-1099.
[2] FRIT B, MERCURIO J P. The crystal chemistry and dielectric properties of the Aurivillius family of complex bismuth oxides with perovskite-like layered structures[J]. Journal of Alloys and Compounds, 1992, 188:27-35.
[3] WU Y, FORBESS M J, SERAJI S, et al. Doping effect in layer structured SrBi2Nb2O9 ferroelectrics[J]. Journal of Applied Physics, 2001, 90(10):5296-5302.
[4] ZHANG X D, YAN H X, REECE M J. Effect of A site substitution on the properties of CaBi2Nb2O9 ferroelectric ceramics[J]. Journal of the American Ceramic Society, 2008, 91(9):2928-2932.
[5] CHEN H B, ZHAI J W. Enhancing piezoelectric performance of CaBi2Nb2O9 ceramics through microstructure control[J]. Journal of Electronic Materials, 2012, 41(8):2238-2242.
[6] GAO P, YAN X, NING P, et al. Ferroelectricity of Pr2Ti2O7 ceramics with super high Curie point[J]. Advances in Applied Ceramics, 2013, 112(2):69-74.
[7] GAO Z P, NING H P, CHEN C, et al. The effect of barium substitution on the ferroelectric properties of Sr2Nb2O7 ceramics[J]. Journal of the American Ceramic Society, 2013, 96(4):1163-1170.
[8] ZHANG S J, YU F P. Piezoelectric materials for high temperature sensors[J]. Journal of the American Ceramic Society, 2011, 94(10):3153-3170.
[9] YAN H, ZHANG H, UBIC R, et al. A lead-free high-curie-point ferroelectric ceramic,CaBi2Nb2O9[J]. Advanced Materials, 2005, 17(10):1261-1265.
[10] YAN H X, ZHANG H T, REECE M J, et al. Thermal depoling of high Curie point Aurivillius phase ferroelectric ceramics[J]. Applied Physics Letters, 2005, 87(8):082911.
[11] YAN H X, REECE M J, LIU J, et al. Effect of texture on dielectric properties and thermal depoling of Bi4Ti3O12 ferroelectric ceramics[J]. Journal of Applied Physics, 2006, 100(7):076103.
[12] ZENG T, YAN H X, REECE M J. Effect of point defects on thermal depoling behavior of bismuth layer-structured ferroelectric ceramics[J]. Journal of Applied Physics, 2010, 108(9):096101.
