激光熔覆层裂纹控制的研究进展

王廷宣; 章健; 刘敬; 宋德琨

doi:10.11973/jxgccl202308001

激光熔覆层裂纹控制的研究进展

王廷宣¹,
章健^1,2,,
刘敬^1,2,
宋德琨¹

1. 安徽理工大学机械工程学院, 淮南 232001;
2. 滨州学院机电工程学院, 滨州 256600

基金项目:

国家自然科学基金资助项目(52205181,52075047)

山东省高等学校青创科技支持计划项目(2022KJ089)

详细信息

作者简介:
王廷宣(1998-),男,山东费县人,硕士研究生

通讯作者:
章健

中图分类号: TG147
计量
- 文章访问数: 5
- HTML全文浏览量: 0
- PDF下载量: 4
出版历程
- 收稿日期: 2022-09-14
- 修回日期: 2023-08-01
- 刊出日期: 2023-08-19

Research Progress on Crack Control of Laser Cladding Layer

1. School of Mechanical Engineering, Anhui University of Technology, Huainan 232001, China;
2. School of Mechanical and Electrical Engineering, Binzhou University, Binzhou 256600, China

摘要

摘要: 激光熔覆技术是一种发展前景广阔的新型表面改性技术,既满足了材料表面特定性能的要求,又节约了大量的贵重元素。裂纹问题是制约激光熔覆技术广泛工业化应用与进一步发展的主要阻碍之一。介绍了激光熔覆层裂纹产生的原因,综述了裂纹的控制措施,包括熔覆层材料成分设计、设置过渡层、工艺参数优化、基体预热、外场(力)辅助等,最后对当前激光熔覆层裂纹控制措施中仍存在的问题进行了总结,并展望了未来的研究方向。
- 激光熔覆 /
- 裂纹 /
- 开裂机理 /
- 残余应力 /
- 控制措施
Abstract: Laser cladding technology is a new type of surface modification technology with broad development prospects, which not only meets the requirements for surface specific properties of materials, but also saves a lot of precious elements. The crack problem is one of the main obstacles restricting the wide industrial application and further development of laser cladding technology. The causes of crack formation in laser clading layers are described, and the crack control measures are reviewed, including the material composition design of cladding layers, setting the transition layer, process parameter optimization, matrix preheating, external field (force) assistance, etc. Finally the problems existing in the current crack control measures of laser cladding layers are summarized, and the future research direction is prospected.
- laser cladding /
- crack /
- cracking mechanism /
- residual stress /
- control measure
