汪 良，等：激光能量密度和固溶处理对激光选区熔化NiTi合金显微组织和性能的影响

650：225-232. HUO M Z，CHEN J，YANG Q，et al. Influence of rod
［19］ 王耀锋，葛进国，袁勃，等. 激光选区熔化制备NiTi合 diameter on dynamic vibration damping characteristics of

金显微组织与压缩性能研究［J］. 热加工工艺，2024， NiTi alloy lattice structure fabricated by selective laser
53（20）：94-99. melting［J］. Chinese Journal of Lasers，2022，49（14）：
WANG Y F，GE J G，YUAN B，et al. Study on 1402305.

microstructural evolution and compression performances ［21］ 王松. 激光选区熔化NiTi合金的微观组织与马氏体相
of selective laser melting NiTi alloy［J］. Hot Working 变行为［D］. 哈尔滨：哈尔滨工程大学，2021.
Technology，2024，53（20）：94-99. WANG S. Microstructure and martensitic transformation
［20］ 霍明政，陈捷，杨琴，等. 杆径对激光选区熔化NiTi合 behavior of NiTi alloy manufactured by selective laser

金点阵结构动态减振特性的影响［J］. 中国激光，2022， melting［D］. Harbin：Harbin Engineering University，
49（14）：1402305. 2021.

Effect of Laser Energy Density and Solid Solution on Microstructure and

Properties of Selective Laser Melted NiTi Alloy

WANG Liang, ZHANG Liang, WU Wenheng

(Shanghai Key Laboratory of Engineering Materials Application and Evaluation, Research and Application Center for Additive
Manufacturing Materials, Shanghai Materials Research Institute Co., Ltd., Shanghai 200437, China)

Abstract: NiTi alloy was prepared by laser selective melting process with NiTi alloy powder as raw materials
−3
under different laser powers and scanning speeds. The effects of laser energy density (26.67‒111.11 J · mm ) and
950 ℃×2 h solid solution on the microstructure, relative density and mechanical properties of NiTi alloy were
investigated. The results show that with the increase of laser energy density, the relative density of the deposited NiTi
alloy firstly increased, then decreased and then slightly increased, and reached the highest value (99.89%) under the laser
−3
energy density of 50.00 J · mm . With the increase of laser energy density, the nickel content in the alloy decreased, the
phase transition temperature increased, the B2 austenite phase decreased, and the B19' martensite phase increased; the
microstructure of the alloy did not change much, and it was equiaxed crystal perpendicular to the forming direction and
columnar crystal parallel to the forming direction; the grain shape changed from irregular shape to regular shape. After
solid solution, the grain morphology did not change significantly, but the structure was more uniform. With the increase of
laser energy density, the tensile strength and percentage elongation after fracture of the deposited and solid-soluted alloys
both basically increased first, then decreased and then increased, and the hardness decreased. When the laser energy
−3
density was 50.00 J · mm , the deposited alloy had the best tensile property, with the tensile strength of 769 MPa and
the percentage elongation after fracture of 6.73%, and after solid solution the tensile strength and percentage elongation
after fracture were 762 MPa, 7.27%, respectively. The optimal SLM process parameters of NiTi alloy were laser power
−1
of 100 W, scanning speed of 800 mm · s , scanning spacing of 100 mm and powder thickness of 30 mm.
Key words: selective laser melting; NiTi alloy; tensile property; solid solution
