郭广飞，等：热输入对低温高锰钢焊接接头组织和性能的影响

tanks［D］. Dongying：China University of Petroleum ［14］ 曾道平，安同邦，郑韶先，等. 热输入对船用440 MPa
（Huadong），2020. 级低合金高强度钢焊缝组织及性能的影响［J］. 焊接学
［11］ 郭广飞，章小浒，任明皓，等. 焊接工艺对LNG储罐 报，2023，44（8）：74-82.

用高锰钢焊接接头组织和性能的影响［J］. 压力容器， ZENG D P，AN T B，ZHENG S X，et al. Effect of heat
2024，41（5）：29-35. input on microstructure and properties of weld seam of
GUO G F，ZHANG X H，REN M H，et al. The effect marine 440 MPa grade HSLA steel［J］. Transactions of
of welding processes on the microstructure and properties the China Welding Institution，2023，44（8）：74-82.

of welded joints of high manganese steel for LNG storage ［15］ 陈亚魁，王红鸿，孟亮，等. 超低温高锰钢埋弧焊焊缝
tanks［J］. Pressure Vessel Technology，2024，41（5）： 金属微观组织及冲击韧性分析［J］. 武汉科技大学学
29-35. 报，2020，43（5）：321-325.
［12］ 杨江. 低温高锰钢焊接热影响区组织演变与力学性能 CHEN Y K，WANG H H，MENG L，et al.

研究［D］. 大连：大连理工大学，2021. Microstructure and impact toughness of submerged-
YANG J. Microstructural evolution and mechanical arc deposited metal for cryogenic high manganese
properties in heat-affected zone of cryogenic high-Mn steel［J］. Journal of Wuhan University of Science and
steel［D］. Dalian：Dalian University of Technology， Technology，2020，43（5）：321-325.

2021. ［16］ 王玉辉. 高锰奥氏体钢的微观组织调控及室温和低温
［13］ 樊晓雨. LNG储罐用高锰钢焊接工艺与焊接接头组织 力学性能［D］. 秦皇岛：燕山大学，2018.

特征及性能研究［D］. 天津：天津理工大学，2022. WANG Y H. Microstructural control for enhancing
FAN X Y. Study on welding process，microstructure and the mechanical properties of high Mn austenitic steel at
properties of high manganese steel joints used in LNG ambient and cryogenic temperatures［D］. Qinhuangdao：
tanks［D］. Tianjin：Tianjin University of Technology， Yanshan University，2018.
2022.

Effect of Heat Input on Microstructure and Properties of Welded Joint of Low
Temperature High Manganese Steel

GUO Guangfei, REN Minghao, JIANG Heng, WU Kai, WANG Zhifu, ZHANG Xiaohu

(Hefei General Machinery Research Institute Co., Ltd., Hefei 230031, China)

Abstract: With CHW-SMn submerged arc welding wire and CHF610 flux, low temperature high manganese
−1
steel was welded by submerged arc welding under different heat inputs (12.0, 16.0, 20.0 kJ · cm ). The effect of heat
input on the microstructure and properties of the joint was studied. The results show that under different heat inputs, the
weld microstructures were all composed of columnar crystal + precipitate, and the microstructures of the heat affected
zone were austenite with a small amount of inclusions and precipitetes. With the increase of heat input, the microstructure
of the heat affected zone was coarsened and the width of the coarse-grained zone increased. With the increase of heat
input, the strength and toughness of the welded joint decreased, and the microhardness of the weld decreased first and
−1
−1
then increased. When the heat input was 12.0 kJ · cm and 16.0 kJ · cm , no cracks were observed on the weld surface
−1
of the welded joint after bending, but cracks appeared when the heat input was 20.0 kJ · cm . The tensile and impact
fracture of the joints under different heat inputs showed dimple morphology, and the fracture modes were all ductile
−1
fracture. When the heat input was 12.0 kJ · cm , the mechanical properties of the welded joint were relatively good.
Key words: low temperature high manganese steel; heat input; microstructure; hardness; impact toughness
