李洋阳，等：双金属复合管中L360MS管线钢焊接接头的疲劳裂纹扩展行为以及疲劳寿命预测

power plant［J］. Acta Metallurgica Sinica，2015，51（4）： SHI Y，YANG X G，YANG D D，et al. Study on
425-439. fatigue crack growth rate of directionally solidified nickel-
［17］ 贾法勇，霍立兴，张玉凤，等. 疲劳裂纹扩展速率两种 based superalloy DZ125［J］. Journal of Mechanical

数据处理方法的比较［J］. 机械强度，2003，25（5）：568- Engineering，2019，55（13），45-52.

571. ［20］ ZHAO Z P，QIAO G Y，TANG L，et al. Fatigue
JIA F Y，HUO L X，ZHANG Y F，et al. Comparison properties of X80 pipeline steels with ferrite/bainite
with two data processing methods on fatigue crack dual-phase microstructure［J］. Materials Science and
growth rate［J］. Journal of Mechanical Strength，2003， Engineering：A，2016，657：96-103.

25（5）：568-571. ［21］ NEWMAN J C，RAJU I S. An empirical stress-intensity
［18］ 陈龙，黄天立，周浩. 基于比例型Paris公式和逆高斯过 factor equation for the surface crack［J］. Engineering

程的金属疲劳裂纹扩展随机模型［J］. 工程力学，2021， Fracture Mechanics，1981，15（1/2）：185-192.
38：238-247. ［22］ ZAHOOR A. Closed form expressions for fracture

CHEN L，HUANG T L，ZHOU H. Stochastic mechanics analysis of cracked pipes［J］. Journal of
modelling of metal fatigue crack growth using Pressure Vessel Technology，1985，107（2）：203-205.
proportional Paris law and inverse Gaussian process［J］. ［23］ 臧路明. 管道结构安全性及剩余寿命评估 ［D］. 天津：

Engineering Mechanics，2021，38（10）：238-247. 天津大学，2007.
［19］ 施祎，杨晓光，杨迪迪，等. 定向凝固镍基高温合金 ZANG L M. Safety and residual life assessment of

DZ125 疲劳裂纹扩展速率研究 ［J］. 机械工程学报， pipeline structure［D］. Tianjin：Tianjin University，2007.
2019，55（13）：45-52.

Fatigue Crack Propagation Behavior and Fatigue Life Prediction of L360MS

Pipeline Steel Welded Joint in Bimetallic Composite Pipe

LI Yangyang , WANG Jixiang , ZHOU Peishan , XU Yingchao , WANG Bin 1
1
3
1
2
(1. School of New Energy and Materials, Southwest Petroleum University, Chengdu 610500, China;
2. China Petroleum Pipeline Research Institute Co., Ltd., Langfang 065000, China;
3. West-East Gas Transmission Branch, Pipe China, Shanghai 200122, China)
Abstract: Multi-layer and multi-pass butt welding of L360MS pipeline steel/N08825 nickel-based alloy bimetallic
composite pipe was carried out by using NiCrMo-3 alloy as welding material. The hardness and tensile properties of
welded joint of L360MS pipeline steel after stripping N08825 nickel-based alloy coating were measured. The fatigue
crack propagation test according to the actual operating conditions was carried out on welded joints of L360MS pipeline
steel. The crack length-cycle number curves in different regions were obtained by using the flexibility method. The
fatigue crack propagation behavior in different regions was studied on the basis of caculation of the Paris formula, and the
fatigue life was predicted. The results show that after tensile test, the joint specimen was fractured at base metal, and
the weld was in a high-strength matching state. The hardness of the weld was in the range of 220‒250 HV, which was
significantly higher than that of the base metal (170‒185 HV). The highest hardness appeared in the weld area adjacent
to the fusion line, and the lowest hardness appeared in the heat affected zone. The fatigue cracks in the base metal,
heat affected zone and weld mainly propagated in intergranular and transgranular modes. However, the fatigue crack
propagation path in the weld was more tortuous, accompanied by bifurcation and even annular cracks. The Paris material
constant C of the heat affected zone was the largest, followed by the base metal, and that of the weld was the smallest.
Under the stress ratio of 0.1, the fatigue crack propagation rates of the base metal and the heat affected zone were faster,
and that of the weld was the slowest. After modifying the material constant C, the life prediction formula of fatigue crack
propagation along the depth direction was obtained. It was predicted that the fatigue life of the heat-affected zone of the
pipe with semi-elliptical cracks along the circumference of the pipe body was the shortest, and the heat-affected zone was
the weakest area of the fatigue performance of the welded joint.
Key words: L360MS pipeline steel; welded joint; fatigue crack propagation; fatigue life
