邸英南，等：不同冶炼工艺生产H13钢中非金属夹杂物特征及其对力学性能的影响

铜TWIP钢拉伸性能的影响［J］. 机械工程材料，2015， metallic inclusion and surface condition on fatigue
39（8）：59-64. property of high strength spring steel［J］. Special Steel，
LIU L L，ZHAO L Y，WANG J L，et al. Influence 1998，19（6）：8-14.

of non-metallic inclusions on tensile properties in high ［16］ 田晶晶，李玉龙，胡广立，等. 两种超高强度钢的拉伸
carbon copper-bearing TWIP steel［J］. Materials for 力学性能研究及断口分析［J］. 兵器材料科学工程，
Mechanical Engineering，2015，39（8）：59-64. 2009，32（4）：31-35.
［15］ 惠卫军，董瀚，陈思联. 非金属夹杂物和表面状态对高 TIAN J J，LI Y L，HU G L，et al. Tensile behavior

强度弹簧钢疲劳性能的影响［J］. 特殊钢，1998，19（6）： and fractography of two kinds of ultra-high strength
8-14. steels［J］. Ordnance Material Science and Engineering，
HUI W J，DONG H，CHEN S L. Influence of non- 2009，32（4）：31-35.

Characteristics of Non-metallic Inclusions in H13 Steel Produced by Different
Smelting Processes and Their Effect on Mechanical Properties

DI Yingnan, MA Dangshen, ZHOU Jian, CHI Hongxiao, GU Jinbo

(Institute of Special Steels, Central Iron and Steel Research Institute, Beijing 100081, China)

Abstract: H13 hot-working die steel was smelted by vacuum induction melting+vacuum arc remelting
(VIM+VAR), electric arc furnace+ladle furnace+vacuum degasses+protective atmosphere electroslag remelting
(EAF+LF+VD+PESR), EAF+LF+VD and EAF+LF+VD+electroslag remelting (ESR) processes, and then
was treated with high temperature diffusion, rolling, austenitizing and tempering. The characteristics of non-metallic
inclusions in H13 steel produced by different smelting processes and their effect on mechanical properties was studied.
The results show that the tempered microstructure of the test steel produced by four smelting processes was composed
of tempered martensite+undissolved carbide+precipitated carbide. The test steel produced by VIM+VAR process had
the lowest content and small-sized non-metallic inclusions, indicating high cleanliness, which led to the best mechanical
properties. The test steel produced by EAF+LF+VD process had the highest content and large size of non-metallic
inclusions, and the carbide particle breakage appeared, resulting in the lowest plasticity of the steel. Small and few non-
metallic inclusions were not easy to be crack sources to accelerate material fracture during the tension process, so higher
cleanliness could improve the mechanical properties of H13 steel.
Key words: smelting process; non-metallic inclusion; hot-working die steel; impact toughness; tensile property
