姚亚俊，等：渗氮X210CrW12钢挺柱的微粒子喷丸工艺

［10］ 栾卫志，姜传海，嵇宁. 喷丸处理对TiB 2 /Al复合材料 nanocrystallization in dry sliding［J］. Tribology，2008，

表面基体力学性能的影响［J］. 材料研究学报，2009， 28（1）：39-43.
23（3）：237-241. ［13］ 李克，朱文龙，宋逸思，等. 复合喷丸对0Cr16Ni5Mo1

LUAN W Z，JIANG C H，JI N. Influence of shot 马氏体不锈钢表面组织和性能的影响［J］. 理化检验(物
blasting on matrix mechanical properties of the surface 理分册)，2021，57（12）：32-37.
on TiB 2 /Al composite［J］. Chinese Journal of Materials LI K，ZHU W L，SONG Y S，et al. Effects of composite
Research，2009，23（3）：237-241. shot peening on surface microstructure and properties of
［11］ LIU H B，ZHU W L，JIANG C H，et al. Microstructure 0Cr16Ni5Mo1 martensitic stainless steel［J］. Physical

evolution and residual stress distribution of Testing and Chemical Analysis（Part A Physical
nanostructured Mg-8Gd-3Y alloy induced by severe shot Testing），2021，57（12）：32-37.
peening［J］. Surface and Coatings Technology，2020， ［14］ 牛童，王昕宇，彭睿智，等. 喷丸对4Cr5Mo2V钢高温

404：126465. 摩擦磨损性能的影响［J］. 机械工程材料，2024，48（3）：
［12］ 李国宾，关德林，张明星. 表面纳米化中碳钢在干摩擦 50-56.

条件下的摩擦磨损性能研究［J］. 摩擦学学报，2008， NIU T，WANG X Y，PENG R Z，et al. Effect of shot
28（1）：39-43. peening on high temperature friction and wear properties
LI G B，GUAN D L，ZHANG M X. Friction and wear of 4Cr5Mo2V steel［J］. Materials for Mechanical
properties of medium carbon steel by means of surface Engineering，2024，48（3）：50-56.

Microparticle Shot Peening Process of Nitrided X210CrW12 Steel Tappet

YAO Yajun , LUO Changzeng 1, 2, 3 , WU Xinbo , XU Deshi , CHEN Yuechun , JIANG Chuanhai 4
1, 2
1, 2
1, 2
1, 2
(1. Weichai Power Co., Ltd., Weifang 261061, China; 2. State Key Laboratory of Engine and Powertrain System,
Weifang 261061, China; 3. College of Materials Science and Technology, Nanjing University of Aeronautics and
Astronautics, Nanjing 211106, China; 4. School of Materials Science and Engineering,
Shanghai Jiao Tong University, Shanghai 200240, China)

Abstract: Taking steel shot with diameter of 0.3 mm, ceramic shot with diameter of 0.1 mm and glass shot
with diameter of 0.1 mm as shots, X210CrW12 steel tappet with overall nitriding was subjected to microparticle
shot peening by using glass shot (shot peening intensity of 0.07 mm, measured by A test piece, the same as
below), ceramic shot (shot peening intensity of 0.15 mm)+glass shot (shot peening intensity of 0.07 mm), and
steel shot (shot peening intensity of 0.30 mm)+ceramic shot (shot peening intensity of 0.15 mm)+glass shot (shot
peening intensity of 0.07 mm). The surface morphology, surface roughness, residual stress, residual austenite
content and microhardness of the tappet after different process shot peening were studied. The results show that
the shot peening had little effect on the surface roughness of nitrided X210CrW12 steel tappet, but could increase
the value and depth of residual compressive stress and hardness of the surface and reduce the residual austenite
content. After shot peening with a single type of glass shot, the tappet surface layer had relatively low and shallow -
distributed residual compressive stress, the relatively high austenite content and the relatively low hardness. Compared
with those after shot-peening with a single type of glass shot, after shot peening with ceramic shot+glass shot, the
residual compressive stress and its layer depth and hardness increased, and the residual austenite content decreased.
After shot peening with steel shot+ceramic shot+glass shot, the surface residual compressive stress was the largest,
with the residual compressive stress on the outer circular surface and the end face of 1 180, 1 238 MPa, respectively,
and the residual compressive stress layer depth was more than 200 µm; the residual austenite content was the lowest,
with the austenite volume fraction on the outer circular surface and the end face of 1.34%, 2.65%, respectively; the
microhardness was the highest, with the hardness on the outer circular surface and the end face of 1 036, 1 009 HV,
respectively; this shot-peening process had the best strengthening effect on the tappet surface layer.
Key words: nitrided X210CrW12 steel tappet; microparticle shot peening; residual stress; austenite content;
hardness
